SPECIFICATION
SilverStone DECATHLON OP700
Switching Power Supply
With Active PFC
PS/2 700W
1. General
This is the specification of Model OP700; it is intended to describe the functions and
performance of the subject power supply. This PS/2 700 watts switching power supply
with Active PFC (Power Factor Correction) capability, meets EN61000-3-2 and equips
Full Range Input features.
2. AC Input Specifications
2-1. AC Input Voltage, Frequency and Current ( Rating: 100V-240Vac, 47-
63Hz, 10-5A )
The power supply must operate within all specified limits over the input voltage range in
Table 1.
Harmonics distortion of up to 10% THD must not cause the power supply to go out of
specified limits.
Table 1 - AC Input Voltage and Frequency
2-2. AC Inrush Current
The power supply must meets inrush requirements of any rated AC voltage, during turn
on at any phase of voltage, during a single cycle AC dropout condition, during repetitive
On/Off cycling of AC, and over the specified temperature range. The peak inrush current
shall be less than the rating of its critical components (including input fuse, bulk rectifiers,
and surge limiting device).
2-3. Input Power Factor Correction ( Active PFC)
The power factor at full load shall be 0.99 at nominal input voltage.
2-4. Input Current Harmonics
When the power supply is operated in 90-264Vac of Sec. 2.1, the input harmonic current
drawn on the power line shall not exceed the limits set by EN61000-3-2 class "D"
standards. The power supply shall incorporate universal power input with active power
factor correction.
2-5. AC Line Dropout
An AC line dropout of 17mS or less shall not cause any tripping of control signals or
protection circuits. If the AC dropout lasts longer than 17mS the power supply should
recover and meet all turn on requirements. The power supply shall meet the regulation
requirement over all rated AC voltages, frequencies, and output loading conditions. Any
dropout of the AC line shall not cause damage to the power supply. An AC line dropout is
defined as a drop in AC line to 0VAC at any phase of the AC line for any length of time.
01
Parameter
Voltage (115V)
Voltage (230V)
Frequency
Norminal
100-120Vac
200-240Vac
50 / 60 Hz
Maximum
132 Vac
264Vac
63 Hz
Max. Current
10A
5A
Minimum
90 Vac
180 Vac
47 Hz
＜
－
