SilverStone ST30GF Инструкция по эксплуатации онлайн
Industry-leading reliability
High efficiency with 80 PLUS Bronze certification
1+1 redundant configuration
Hot swappable design
Convenient pull-out handle bars
Active PFC (full range)
Dual 40mm DC cooling fans
1U redundant power supply with 106mm (W) x 41.5mm (H) x 270mm (D)
300W + 300W 24hour fully continuous power output
Serial ATA support
ST30GF
August, 2011
Always up reliability and redundancy in super small form factor
Содержание
- Always up reliability and redundancy in super small form factor 1
- August 2011 1
- St30gf 1
- St30gf mauual v1 封面底 1
- Ac input specifications 2
- Dc output specification 2
- General 2
- Silverstone gemini st30gf 1u narrow redundant switching power supply with active pfc 300w 300w 2
- Specification 2
- St30gf 2
- St30gf mauual v1 p1 p2 2
- All main output must be within regulation 3
- All main output must leave regulation 3
- Description 3
- Main output 5vsb 70ms 3
- Of each other within this time 3
- Output voltage rise time from each 3
- Ripple and noise shall be measured using the following methods a measurements made differentially to eliminate common mode noise b ground lead length of oscilloscope probe shall be 0 5 inch c measurements made where the cable connectors attach to the load d outputs bypassed at the point of measurement with a parallel combination of 10uf tantalum capacitor in parallel with a 0 uf ceramic capacitors e oscilloscope bandwidth of 0 hz to 20mhz f measurements measured at locations where remote sense wires are connected g regulation tolerance shall include temperature change warm up drift and dynamic load 3
- St30gf 3
- St30gf mauual v1 p3 p4 3
- Table 4 output voltage timing 3
- Table 5 turn on off timing 3
- These are the timing requirements for the power assembly operation the output voltages must rise from 10 to within regulation limits tvout_rise within 5 to 70ms the 5v 3 v and 12v output voltages should start to rise at about the same time all outputs must rise monotonically the 5v output must occur first than the 3 v output during any point of the voltage rise the 5v output must never be greater than the 3 v output by more than 2 5v each output voltage shall reach regulation within 50 ms tvout_on of each other during turn on of the power supply each output voltage shall fall out of regulation within 400 ms tvout_off of each other during turn off figure 1 and figure 2 shows the turn on and turn off timing requirement in figure 2 the timing is shown with both ac and pson controlling the on off of the power supply 3
- Timing requirements 3
- Tvout_off 3
- Tvout_on 3
- Tvout_rise 3
- Within this time 3
- Environmental requirements 4
- Protection 4
- St30gf 4
- St30gf mauual v1 p5 p6 4
- Agency requirements 5
- Redundant power supply function 5
- St30gf 5
- St30gf mauual v1 p7 p8 5
- Atx 12v 4pin connector 6
- Dimension 6
- Eps 12v 8pin connector 6
- Pin peripheral connector 4pin floppy connector 6
- Reliability 6
- Sata connector 6
- St30gf 6
- St30gf mauual v1 p9 p10 6
