02
Notes:
(1) The maximum continuous total DC outputs power shall not exceed 500W
(2) The maximum peak total DC output power shall not exceed 520W
(Peak current may last up to 17 seconds with not more than one occurrence per minute).
(3) The maximum continuous load on +5V and +3.3V outputs shall not exceed 150W.
(4) The maximum combined current for the +12V outputs shall be 36A
(5) 12V1DC and 12V2DC should have separate current limit circuits to meet 240VA safety
requirements.
2.2 Load ranges
Nom Peak Unit
Amps
Min
0.0
0.0
1.0
1.0
0.0
0.0
19.0
Amps
19.0 Amps
Amps
3.5
Amps
Max
25.0
25.0
18.0
18.0
0.3
3.0 Amps
-
-
-
-
-
-
Parameter
+3.3V
+5V
-12V
+12V1
+12V2
+5VSB
2.2.1 : (500 Watts Load Ratings)
2. DC OUTPUT
2.1 DC voltage regulation
Min Max Unit
+3.40 Volts
Range
+/-3%
+/-3%
+/-3%
+/-3%
+/-10%
+/-3%
+3.20
+5.15 Volts+4.85
+12.36 Volts+11.64
+12.36 Volts+11.64
-13.2 Volts-10.8
+5.15
Nom
+3.3
+5
+12
+12
-12
+5 Volts+4.85
Parameter
+3.3V
+5V
-12V
+12V1
+12V2
+5VSB
ELEMENT ST50EF-PLUS-SC
