Specifications SiBE041213E
5 Specifications
Note:
The data are based on the conditions shown in the table below.
50 Hz, 220 - 230 - 240 V
Model
Indoor Unit FTXS50K2V1B
Outdoor Unit
RXS50K2V1B
Cooling Heating
Capacity Rated (Min. ~ Max.)
kW 5.00 (1.7 ~ 5.3) 5.80 (1.7 ~ 6.5)
Btu/h 17,100 (5,800 ~ 18,100) 19,800 (5,800 ~ 22,200)
kcal/h 4,300 (1,460 ~ 4,560) 4,990 (1,460 ~ 5,590)
Moisture Removal L/h 2.8 —
Running Current (Rated) A 6.6 - 6.3 - 6.0 6.8 - 6.5 - 6.2
Power Consumption
Rated (Min. ~ Max.)
W 1,410 (350 ~ 1,810) 1,450 (300 ~ 2,000)
Power Factor % 97.1 - 97.3 - 97.9 96.9 - 97.0 - 97.4
COP (Rated) (Min. ~ Max.) W/W 3.55 (4.86 ~ 2.93) 4.00 (5.67 ~ 3.25)
Piping
Connections
Liquid mm φ 6.4
Gas mm φ 12.7
Drain mm φ 18.0
Heat Insulation Both Liquid and Gas Pipes
Max. Interunit Piping Length m 30
Max. Interunit Height Difference m 20
Chargeless m 10
Amount of Additional Charge of
Refrigerant
g/m 20
Indoor Unit FTXS50K2V1B
Front Panel Color White
Airflow Rate
H
m³/min
(cfm)
11.9 (420) 13.3 (470)
M 9.6 (339) 10.8 (381)
L 7.4 (261) 8.4 (297)
SL 4.5 (159) 5.5 (194)
Fan
Type Cross Flow Fan
Motor Output W 23
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable, Washable, Mildew Proof
Running Current A 0.12 - 0.12 - 0.11 0.15 - 0.14 - 0.14
Power Consumption W 26 - 26 - 26 32 - 32 - 32
Power Factor % 98.5 - 94.2 - 98.5 97.0 - 99.4 - 95.2
Temperature Control Microcomputer Control
Dimensions (H × W × D) mm 298 × 900 × 215
Packaged Dimensions (H × W × D) mm 290 × 977 × 371
Weight (Mass) kg 11
Gross Weight (Gross Mass) kg 15
Sound Pressure Level (H / M / L / SL) dB(A) 46 / 40 / 34 / 23 47 / 40 / 34 / 24
Sound Power Level dB 60 60
Outdoor Unit RXS50K2V1B
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 2YC36BXD
Motor Output W 1,100
Refrigerant
Oil
Type FVC50K
Charge L 0.650
Refrigerant
Type R-410A
Charge kg 1.7
Airflow Rate
H
m³/min
(cfm)
50.9 (1,797) 45.0 (1,589)
SL 48.9 (1,727) 43.1 (1,522)
Fan
Type Propeller
Motor Output W 53
Running Current A 6.48 - 6.18 - 5.89 6.65 - 6.36 - 6.06
Power Consumption W 1,384 - 1,384 - 1,384 1,418 - 1,418 - 1,418
Power Factor % 97.1 - 97.4 - 97.9 96.9 - 96.9 - 97.5
Starting Current A 6.8
Dimensions (H × W × D) mm 735 × 825 × 300
Packaged Dimensions (H × W × D) mm 797 × 992 × 390
Weight (Mass) kg 47
Gross Weight (Gross Mass) kg 52
Sound Pressure Level (H / SL) dB(A) 48 / 44 48 / 45
Sound Power Level (H) dB 63 63
Drawing No. 3D080621
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB / 6°CWB
5 m
