Daikin FTXS60FV1B [4/12] Specifications
![Daikin FTXS71FV1B [4/12] Specifications](/views2/1720421/page4/bg4.png)
3
2
• Split Sky Air • Indoor Units
3
• Indoor Units • R-410A • FTXS-FV1B
2 Specifications
2-1 FOR INDOOR UNITS ONLY FTXS50FV1B FTXS60FV1B FTXS71FV1B
Nominal input
(Indoor only)
Cooling kW 0.034 0.04 0.045
Heating kW 0.036 0.045 0.060
2-2 TECHNICAL SPECIFICATIONS FTXS50FV1B FTXS60FV1B FTXS71FV1B
Casing Colour White
Dimensions Packing Height mm 337 337 337
Width mm 1147 1147 1147
Depth mm 366 366 366
Unit Height mm 290 290 290
Width mm 1050 1050 1050
Depth mm 238 238 238
Weight Unit kg 12 12 12
Packed Unit kg 17 17 17
Heat Exchanger Dimensions Length mm 863 863 863
Nr of Rows 2 2 2
Fin Pitch mm 1.4 1.4
Nr of Stages 16 16 16
Tube type Hi-XA (7)
Fin Type ML fin (Multi louver)
Fan Type Cross flow fan
Quantity 1 1 1
Air Flow Rate Cooling High m³/min 14.7 16.2 17.4
Medium m³/min 12.4 13.6 14.6
Low m³/min 10.3 11.4 11.6
Silent Operation m³/min 9.5 10.2 10.6
Heating High m³/min 16.1 17.4 19.7
Medium m³/min 13.9 15.1 16.9
Low m³/min 11.5 12.7 14.3
Silent Operation m³/min 10.2 11.4 12.7
Fan Motor Quantity 1 1 1
Model ARW30R8P43DA
Number of steps 5 5 5
Motor Speed (cooling) High rpm 1240 1330 1410
Medium rpm 1090 1170 1220
Low rpm 930 1010 1040
Silent Operation rpm 860 920 950
Speed (heating) High rpm 1270 1360 1520
Medium rpm 1120 1200 1330
Low rpm 960 1040 1150
Silent Operation rpm 870 950 1040
Fan Motor Output (high) W 43 43 43
Cooling Sound Power Medium dBA 59 61 62
Sound Pressure High dBA 43 45 46
Medium dBA 39 41 42
Low dBA 34 36 37
Silent Operation dBA 31 33 34
Heating Sound Power Medium dBA 58 60 62
Sound Pressure High dBA 42 44 46
Medium dBA 38 40 42
Low dBA 33 35 37
Silent Operation dBA 30 32 34
Refrigerant Type R-410A
Piping connections Liquid (OD) Diameter (OD) mm 6.4 6.4 6.4
Gas Diameter (OD) mm 12.7 12.7 15.9
Drain Diameter (OD) mm 18 18 18
Heat Insulation Both liquid and gas pipes
Air Filter Removable/washable/Mildew proof
Air direction control Right, Left, Horizontal, Downward
