Outdoor Unit SiBE12-713
304 Removal Procedure
3. Disconnect the wire
harnesses
4. Remove the terminal
board
★ Illustrations are for 3 room
model.
1
Open the electrical box
and remove the
terminal board.
Step
Procedure Points
