2 En
English
• Install the speakers in a cool, dry, clean, stable and horizontal
place.
• To avoid electric shock, fire, injury, damage to the speakers, and
discoloration of the cabinet, install away from windows, heat
sources, sources of excessive vibration, dust, moisture, cold, rain,
water, falling objects, noise sources (transformers, motors, etc.)
and direct sunlight.
• Do not insert a hand or object into the port or pick up the speaker
by holding the port, as it may cause personal injury or damage to
the speaker.
• Any time you note distortion, reduce the volume control on your
receiver to a lower setting. Never allow your receiver to be driven
into “clipping”. Otherwise the speakers may be damaged.
• When using a receiver with a rated output power higher than the
nominal input power of the speakers, care should be taken never
to exceed the speakers’ maximum input.
• Do not attempt to clean the speakers with chemical solvents (ex.
alcohol or thinners etc.); this might damage the finish. Use a
clean, dry cloth.
• Do not attempt to modify or fix the speakers. Contact qualified
Yamaha service personnel when any service is needed. The cabi-
net should never be opened for any reasons.
• Secure placement or installation is the owner’s respon-
sibility. Yamaha shall not be liable for any accident
caused by improper placement or installation of speak-
ers.
The following items are included.
Speaker cable (2 m) × 2 / Grille × 2
The speaker and the grille are packed
separately. To attach the grille, line up
the projections (magnets) on the reverse
side of the grille with their
corresponding screw heads on the
speaker.
When the grille is removed, be sure not to touch the
speaker units with your hands or to exert excessive force
with tools.
BEFORE MAKING CONNECTIONS, MAKE SURE THAT
THE RECEIVER IS SWITCHED OFF.
When this unit is connected to the receiver, refer also to the owner’s
manual supplied with the receiver.
See page 1 for the connection method.
• Place the speakers on a sturdy, vibration-free surface.
• Better stereo images will be obtained when the speakers are
slightly angled in towards the listening position.
• Be sure to connect the left channel (L) and right channel (R)
properly.
Placing the speakers too close to a CRT-type TV may
impair the picture color or cause a buzzing noise. In this
case, move the speakers away from the TV. This is not an
issue with LCD and plasma TVs.
Type ..............................................2-way bass-reflex speaker system
Non-magnetic shielding Type
Driver.....................................................12 cm (4-3/4") cone woofer
3 cm (1-1/4") soft dome tweeter
Impedance................................................................................... 6 Ω
Frequency Response................................. 60 Hz to 40 kHz (-10 dB)
100 kHz (-30 dB)
Nominal Input Power ................................................................40 W
Maximum Input Power............................................................110 W
Sensitivity.............................................................83 dB/2.83 V, 1 m
Crossover Frequency ................................................................5 kHz
Dimensions (W × H × D) ...............................154 × 273 × 230 mm
(6" × 10-6/8" × 9")
Weight....................................................................... 3.3 kg (7.2 lbs.)
* Specifications are subject to change without notice due to
product improvements.
* Care should be taken not to exceed the input power values noted
above.
PRECAUTIONS
ACCESSORIES
ATTACHING THE GRILLE
Note
CONNECTION TO YOUR RECEIVER
PLACING THE SPEAKERS
Note
SPECIFICATIONS
(L) (R)
