23
The Even Feed Foot Accessory (Optional)
Always try to sew first without the Even Feed Foot accessory
which should be used only when necessary.
It is easier to guide the fabric and you have a better view of
the seam when using the standard, regular foot on your
machine. Your sewing machine offers excellent stitch quality
on a wide range of fabrics from delicate chiffons to multiple
layers of denim.
The Even Feed Foot accessory equalizes the feeding of the
upper and lower layers of fabric and improves the matching
of plaids, stripes and patterns. It also helps to prevent
uneven feeding of very difficult fabrics.
1. Lift the presser foot lifter to raise the presser foot bar (a).
2. Remove the presser foot shank by unscrewing (counter-
clockwise) the presser bar attaching screw (b).
3. Attach the Even Feed Foot to the machine as follows:
i) The arm (c) should fit into above the needle screw
and clamp (d).
ii) Slide the plastic attaching head (e) from your left to
right so that it is fitted into the presser foot bar.
iii) Lower the presser foot bar (a).
iv) Replace and tighten (clockwise) the presser bar
attaching screw (b).
4. Make sure both the needle screw (d) and the presser bar
attaching screw (b) are tightly secured.
5. Draw the bobbin thread up and place both the bobbin
thread and the needle thread behind the Even Feed Foot
attachment.
Arm (c)
Attaching head (e)
Presser bar attaching screw (b)
Needle screw & clamp (d)
Needle
bar
presser foot bar (a)
Arm (c)
