Ubiquiti NanoStation Loco M2 [5/13] Datasheet
![Ubiquiti NanoStation Loco M900 [5/13] Nsm_ds_05](/views2/1072145/page5/bg5.png)
05
Ubiquiti Networks, Inc. Copyright © 2011, All Rights Reserved www.ubnt.com
Specifications
Max Power Consumption 8 Watts5.5 Watts6.5 Watts
Polarization Dual Linear
RF Connector --External RP-SMA
Antenna Gain 11 dBi (M2)
13.7 dBi (M3/M365)
16 dBi (M5)
8 dBi (M2)
13 dBi (M5)
8 dBi
System Information
Memory Information 64MB SDRAM, 8MB Flash 32MB SDRAM, 8MB Flash
Regulatory / Compliance Information
LOCOM9 M2, M5** NSM365NSM3
LOCOM9 LOCOM, NSM
Networking Interface 1 X 10/100 BASE-TX (Cat. 5, RJ-45) Ethernet 2 X 10/100 BASE-TX (Cat. 5, RJ-45) Ethernet
LOCOM NSM
Wireless Approvals FCC Part 15.247, IC RS210 FCC Part 15.247, IC RS210, CE FCC Part 90Z-
RoHS Compliance YES
Physical / Electrical / Environmental / Antenna
Weight 0.18 kg0.9 kg 0.4 kg
0.5 kg (M3/M365)
Enclosure Characteristics Outdoor UV Stabilized Plastic
Mounting Kit Pole Mounting Kit included
Power Method Passive Power over Ethernet (pairs 4, 5+; 7, 8 return)
Operating Temperature -30C to 75C
Operating Humidity 5 to 95% Condensing
Shock and Vibration ETSI300-019-1.4
Processor Specs Atheros MIPS 24KC, 400MHz
Dimensions 164 x 72 x 199 mm
LOCOM9
163 x 31 x 80 mm
LOCOM
294 x 31 x 80 mm
NSM
Power Supply (included) 24V, 0.5A POE
24V, 1A POE (M3/M365)
24V, 0.5A POE24V, 1A POE
Operating Frequency Summary (MHz)
M2**
2412-2462
NSM3
3400-3700
NSM365
3650-3675
M5**
5470-5825*
LOCOM9
902-928
* Only 5745 - 5825 MHz is supported in the USA
** Applies to both NanoStation M and NanoStation Loco M models
