Telefunken TF-DVR32FHD [5/20] Playback mode

Instruction manual

shown in red figures in the top right corner of

the display. The unit will save video files

automatically after each 1, 3 or 5 minutes

(see “Setup“ paragraph below for more details).

When the memory card is full, old files will be

deleted and the new files will be recorded

instead. Press OK button to stop and to

continue recording.

Playback mode

• Stop the recording and press MODE

to enter playback mode. Press UP/DOWN

button to choose the file. Press and hold the

UP button to select the rearview camera file.

Press OK button to play the selected file.

Press OK button to stop or resume playback.

• In file playback mode select a file, then

hold the MENU button. A menu will appear in

which you can select to delete or protect the

file. Select either option, then press OK

button to confirm.

HDMI

• The HDMI output is used to connect the

included wired rearview camera.

Setup

In recording mode press the MODE button to

choose the needed operation mode (Video/

Photo/Playback). Press M to enter the setup

menu for the current mode.

In the menu press UP/DOWN buttons to select

settings. Press OK button to go

to adjustment of the selected setting; select

options with cursor button and press OK button

to confirm.

Some menu items may be in grey

color, in this case they are not adjustable. The

menu in your unit may be changed without

prior notice and hence be different from the

menu described below.

General system setup

• LCD off: activate and set the idle time

period of the screen saver or turn it off.

• Auto Power Off: Off / 3 minutes / 5

minutes / 10 minutes: select the time period

after which the unit will automatically switch

off, or disable this function.

• Frequency: 50 Hz/60 Hz.

• Before removing memory card stop

recording. Press on the card until a click to

remove it.

• Motion detector recording is available after

you switch on this item in the setting menu (see

“Setup“ paragraph below for more details). The

unit will go to recording mode if there is image

motion in front of the lens. When a motion is

detected, the unit will start to record a video

fragment (no matter whether there is motion or

not during the recording period), after the

fragment is recorded, the unit comes to standby

mode till a motion is detected again.

• G-sensor. If overload resulting from an

impact exceeds the setup value (1 g = 9.8m/s

;

see “Setup“ paragraph below for more details),

the current video fragment will be automatically

protected from re-recording.

• SOS function. When you press Lock button

during video recording, the current fragment will

be protected from rerecording.

• During recording press DOWN to mute the

sound.

• Press the MODE button repeatedly to

switch between video recording, photo and

playback modes.

PC connection

• Connect the unit to a computer using a

USB connection cable (not included). Now the

unit can be used as a mass storage device

("Mass Storage") or as a webcam for your PC

("PC Camera").

• The automatic driver management

software will launch on the PC. Follow the on-

screen instructions to properly install the

camera driver.
