1. General

This specification describes the electrical characteristics, functional and physical of a PS/2

750 watts switching power supply with Active PFC (Power Factor Correction) capabilities.

2. AC Input Characteristics

2.1 AC Input Voltage, Frequency and Current ( Rating: 100V-240Vac, 47-63Hz, 12-6A )

The power supply must operate within all specified limits over the input voltage range in Table 1.

Harmonics distortion of up to 10% THD must not cause the power supply to go out of specified limits.

2.2 AC Inrush Current

AC line inrush current shall not damage any component nor cause the AC line fuse to blow

under any DC conditions and with any specified AC line input voltage and frequency. Repetitive

On/Off cycling of the AC input voltage shall not damage the power supply.

2.3 Input Power Factor Correction ( Active PFC)

The power factor at full load shall be

≧

0.95 at nominal input voltage.

SilverStone Zeus ST75ZF

Switching Power Supply

With Active PFC

PS/2 750W

SPECIFICATION

Parameter RatedMinimum Maximum Max. Current

132 Vac 12A

Voltage (115V) 90 Vac 100-120Vac

Voltage (230V)

Frequency

180 Vac 200-240Vac

50 / 60 Hz

264Vac

63 Hz

47 Hz

Table 1 - AC Input Voltage and Frequency
