• ARM1136JF-S CPU

• Vector Floating Point Unit

• L1 cache 16 KB/16 KB (D/I)

• TCM 16 KB/16 KB (D/I)

Memory Subsystem

• System bus 64-bit

• DMA 16 channels

• Mobile-DDR, DDR2 support

GPS/Galileo Receiver

• 64 channels, high sensitivity

Storage

• Direct boot from 8-bit SLC/MLC NAND Flash

• SDHC/SD 2.0/MMC4.x (x4)

• Direct boot from iNAND/MoviNAND

Display, Graphics, Multimedia

• Up to 800 x 480, 16 bit color

• RGB565 or 16 bit CPU I/F TFT LCD panel

• Hardware VPP (video post processor) for deinterlace, scaler, color space conversion

• Two hardware overlay layers

Peripheral Connectivity

• AC97/I2S

• UART (x2), USP for PCM, DSP, I2S, SPI, UART, irDA, I2C (x2)

• 12-bit ADC with touch screen controller

• High-speed USB 2.0 OTG

• SD/MMC+/SDIO (x4) for WiFi, mDTV, NAND storage, memory card

• High-performance GPS and Galileo location engine

• Integrated power management unit

• 500 or 664 MHz high-speed ARM11 CPU with vector floating point unit

• DDR2, Mobile DDR, SD/MMC/MMC+ and NAND flash memory controllers

• Audio DAC; LCD touch panel controller and video post processing accelerator

• Supports QVGA H.264 mobile digital TV content and VGA MPEG4 video playback

• Advanced memory controller supports 166 MHz clock Mobile-DDR and 200 MHz clock DDR2

• Embedded hardware for color space conversion, deinterlace, and scaler

• 8-bit NAND flash interface with 12/24-bit configurable BCH HW ECC support for direct boot from

SLC or MLC NAND

• Integrated four port SD/MMC/MMC+ controller and support for direct boot

• High-speed USB 2.0 port with internal PHY configurable as host or slave

• CSRsynergy supports Bluetooth, Bluetooth low energy, Wi-Fi, echo cancellation, noise

suppression, FM receive and transmit and more
