IMPORTANT NOTES
The smartphone must be balanced to guarantee the correct functioning of the stabilizer.
Turn on the stabilizer only when the smartphone is mounted, otherwise motors might be damaged.
Vibrating is normal for the first few seconds after turning on the stabilizer. It will disappear when
the motor's auto-adjustment is done.
Do not force the motors to rotate rapidly since they cannot spin 360°.
Keep the stabilizer away from impact when the telescopic handle is extended. (as shown in Figure a)
When the stabilizer is powered on, don't grab the top part. (as shown in Figure b)
If placing the stabilizer on a flat surface, put the stabilizer on a tripod to ensure it is upright. (as
shown in Figure c)
Keep the stabilizer away from water.
The stabilizer is not compatible with quick chargers.
Figure a Figure b Figure c
Power on
11
