21
ENGLISH
BLUETOOTH MODE
---------------------------------------------------------------------------------------------------
7
The M 2200 automatically connects to the
last Bluetooth auxiliary device that was
logged on.
7
If the Bluetooth auxiliary device is not recog-
nised, it has to be activated again via its own
menu.
Playback from the Bluetooth
auxiliary device
1 Start playback on the Bluetooth auxiliary de-
vice.
2 Set the preferred volume with »VOLUME« on
the hi-fi or »– VOL +« on the remote control.
3 End playback on the Bluetooth auxiliary de-
vice.
Notes:
7
Various functions can also be controlled on
the M 2200.
Press »eII« to pause playback,
press »eII« again to resume playback;
press »5« to select the previous track and
»6« for the next track.
7
Note that the data transmission range can
be as much as 9 m, depending on the Blue-
tooth device that is used and the structure of
the building.
Logging out the Bluetooth auxiliary
device
1 Log out the Bluetooth device or press and hold
down »
7
/PAIRING« on the M 2200.
– The display changes to »SEARCHING«.
Logging the Bluetooth device back
on
1 If you move out of data transmission range or
switch off Bluetooth mode, the Bluetooth auxil-
iary device is logged out.
2 To log back on, select your M 2200 again on
the Bluetooth auxiliary device.
Note:
7
If it is not possible to connect to a Bluetooth
auxiliary device that was registered previ-
ously, remove your M 2200 from the Blue-
tooth auxiliary device's device list and re-
peat the search and connection procedure.
Compatible with the following
devices
Your M 2200 can be connected to any com-
mercially available Bluetooth-compatible de-
vices that comply with the A2DP standard. This
includes smartphones, laptops and tablet PCs,
for example.
Selecting the Bluetooth input
source
1 Select the Bluetooth input source by pressing
»SOURCE« on the device or » « on the re--
mote control.
– Display: »BT DISCONNECT«.
Finding and connecting a Blue-
tooth auxiliary device
1 Activate the Bluetooth function on the Blue-
tooth auxiliary device.
2 Start the search function on the Bluetooth aux-
iliary device.
– After a short time, your M 2200 will be dis-
played on the Bluetooth auxiliary device.
3 Select the M 2200 on the Bluetooth auxiliary
device and connect to it.
4 When the Bluetooth auxiliary device is con-
nected to your device, »BT« is displayed on
the M 2200.
Note:
7
Your M 2200 can only receive and play
the audio signal from one Bluetooth device;
however, up to 8 Bluetooth auxiliary devices
can be logged on.
Activating a Bluetooth auxiliary
device that is logged on
Notes:
7
You only have to log Bluetooth auxiliary de-
vices on once.
7
When the Bluetooth auxiliary device leaves
and then moves back into signal range of
the M 2200, the auxiliary device logs on
automatically.
