SiBE05-311 List of Functions
List of Functions 3
1.2 Heat Pump
Category Functions
FLXS25·35BVMB
RXS25·35BVMB
FLX25·35BVMB
RX25·35BVMB
Category Functions
FLXS25·35BVMB
RXS25·35BVMB
FLX25·35BVMB
RX25·35BVMB
Basic
Function
Inverter (with Inverter Power Control)
Health &
Clean
Air Purifying Filter with Bacteriostatic,
Virustatic Functions
Operation Limit for Cooling (˚CDB)
–10
~46
10
~46
Operation Limit for Heating (˚CWB)
–15
~15.5
–10
~15.5
Photocatalytic Deodorizing Filter —
PAM Control —
Air Purifying Filter with Photocatalytic
Deodorizing Function
——
Compressor
Oval Scroll Compressor — — Longlife Filter — —
Swing Compressor Ultra-Longlife Filter (Option) — —
Rotary Compressor — — Mold Proof Air Filter
Reluctance DC Motor — Wipe-clean Flat Panel — —
Comfortable
Airflow
Power-Airflow Flap — — Washable Grille — —
Power-Airflow Dual Flaps — — Filter Cleaning Indicator — —
Power-Airflow Diffuser — — Good-Sleep Cooling Operation — —
Wide-Angle Louvers — —
Timer
24-Hour On/Off Timer
Vertical Auto-Swing (Up and Down) Night Set Mode
Horizontal Auto-Swing (Right and Left) — —
Worry Free
“Reliability &
Durability”
Auto-Restart (after Power Failure)
3-D Airflow — — Self-Diagnosis (Digital, LED) Display
3-Step Airflow (H/P Only) — — Wiring Error Check — —
Comfort
Control
Auto Fan Speed
Anticorrosion Treatment of Outdoor
Heat Exchanger
Indoor Unit Silent Operation
Night Quiet Mode (Automatic) — —
Flexibility
Multi-Split / Split Type Compatible
Indoor Unit
—
Outdoor Unit Silent Operation (Manual) —
Intelligent Eye — — Flexible Voltage Correspondence
Quick Warming Function High Ceiling Application — —
Hot-Start Function Chargeless 10m 10m
Automatic Defrosting Power Selection — —
Operation
Automatic Operation
Remote
Control
5-Rooms Centralized Controller
(Option)
Programme Dry Function
Remote Control Adaptor
(Normal Open-Pulse Contact)(Option)
Fan Only
Lifestyle
Convenience
New Powerful Operation (Non-Inverter) — —
Remote Control Adaptor
(Normal Open Contact)(Option)
Inverter Powerful Operation
Priority-Room Setting — — DIII-NET Compatible (Adaptor)(Option)
Cooling / Heating Mode Lock — —
Remote
Controller
Wireless
Home Leave Operation Wired — —
Indoor Unit On/Off Switch
Signal Reception Indicator
Temperature Display — —
Another Room Operation — —
Note: : Holding Functions
— : No Functions
: Digital Only
