Installation

Refrigerator/User Manual

Installation (Under the counter)

• Internal height of the counter should be

820mm.

• (!) Cookers or other heat sources must not

be placed above the counter where the

appliance is installed under the counter.

• The mains wall socket plug must be clo-

se to the right or left hand side of the app-

liance.

• Remove the top cover of the appliance.

There are 4 screws(2 pieces at the back,

2 pieces below the front edge) that should

be removed. Fig. 1

• Cut the part shown in the picture and then

remove it by the help of pliers.

• Place you appliance under the counter

and adjust the front feets until its top touc-

hes to the counter.

• In order to use the product under the coun-

ter, the distance between the wall and the

reference indicated in the top connection

plastic must be minimum 595 mm.

Fig. 2-3

• Fix the appliance under the counter by

using 2 of the screws that was removed

from the top cover.(Material of the counter

must be plastics or wood based!)

Fig. 4
