7English

1. To install the air cleaner above the stove, draw a vertical line on the wall

from the center of the stove vertically to the ceiling. To comply with safety

regulations, the distance between the cooking surface and the air cleaner should

be 700 mm. Accordingly, make a mark with a pencil on the vertical line at a height

of 700+426=1126 mm from the surface of the stove. Draw a horizontal line through

this point on the wall. Measure 100 mm on this line to the right and left from the

point of intersection of the vertical and horizontal lines and make marks with a

pencil. Using a 6-mm drill bit, drill holes in these marks. Insert dowels in the holes

just drilled and fi x the hooks.

2. Installation of decorative cover Draw a horizontal line on a wall, at a distance

of 75 mm from the ceiling. Measure 50 mm on this line to the right and left from the

point of intersection with the vertical line and make marks with a pencil. On these

marks, drill the holes, insert the 8-mm dowels in them and tighten 2.5-mm screws

which must protrude 2 mm from the wall.

Step 1: Installation of hooks

Step 2: Installation of mounting bracket

Step 3: Installation of housing

Step 4: Installation of external part of decorative cover

Step 5: Installation of internal part of decorative cover

1- Ø8 dowel

2- Mounting bracket

3- Hook

4- Internal part of decorative cover

5- External part of decorative cover

6- Air cleaner housing

7- Bushing adapter

8- Ø 2.5 screw
