42 / 60 EN
Dryer / User Manual
Preparation
Dry the same type of laundry together.
Follow the instructions in the user manual
for programme selection.
Leave sufficient clearance at the front and
rear side of the dryer for air circulation.
Do not block the ventilation grills at the
front side of the product.
Do not open the loading door of the
machine during drying unless necessary.
If you must certainly open the loading
door, do not to keep it open for a long
time.
Do not add new (wet) laundry during
drying.
Lint and fiber released from the laundry
to the air during the drying cycle are
collected in the Lint Filter. Clean the lint
filter before or after each drying cycle.
Clean the filter drawer regularly either
when the Filter Drawer Cleaning warning
symbol appears or after every 5 drying
cycles.
Ventilate the room, where the dryer is
located, well during drying.
4.4 First use
Before starting to use the product, make sure
that all preparations are in place pursuant to
the instructions in sections “Important Safety
Instructions” and “Installation”.
4.5 Correct load capacity
Follow the instructions in the “Programme
selection and consumption table”. Do not load
more than the capacity values stated in the
table.
C
It is not recommended to load the
dryer with laundry exceeding the
level indicated in the figure. Drying
performance will degrade when the
machine is overloaded. Furthermore,
dryer and the laundry can get
damaged.
Following weights are given as examples.
Home articles
Approximate
weights (g)
Cotton quit covers (double) 1500
Cotton quit covers (single) 1000
Bed sheets (double) 500
Bed sheets (single) 350
Large tablecloths 700
Small tablecloths 250
Tea napkins 100
Bath towels 700
Hand towels 350
Garments
Approximate weights
(g)
Blouses 150
Cotton shirts 300
Shirts 200
Cotton dresses 500
Dresses 350
Jeans 700
Handkerchiefs (10 pieces) 100
T-Shirts 125
