Ubiquiti UniFi Video Camera PRO [15/24] Specifications
![Ubiquiti UniFi Video Camera PRO [15/24] Specifications](/views2/1072864/page15/bgf.png)
Specifications
UniFi Video Camera PRO
Dimensions 322 x 100 x 100 mm (12.67 x 3.93 x 3.93")
Weight 2.15 kg (4.73 lbs)
Ports (1) 10/100 Ethernet Port
Sensor 3M WDR Sensor
Lens 3X Optical Zoom, f= 3-9 mm
Infrared Yes
Buttons Factory Reset Button
Power Method Passive PoE (48V, 0.5A), 802.3af
Power Supply 48V, 0.5A PoE Adapter Included
Max. Power Consumption 12.5 W
Certications CE, FCC, IC
Mounting Pole/Wall/Ceiling Adapter Kit Included
Protection Rating IP67 Waterproof
Operating Temperature -40 to 50° C (-40 to 122° F)
Operating Humidity 20 - 90% Non-Condensing
Video
Video Compression H.264
Resolution 1080p Full HD
Maximum Frame Rate 30 FPS
Image Setting Brightness, Contrast, Sharpness, Saturation,
Noise Reduction, 50 Hz/60 Hz
General
Processor ARM 1136J-S 528 MHz
Memory 256 MB DDR3, 256 MB Flash
View Angle 44.4° W - 15.7° T (V)
81.0° W - 27.9° T (H)
94.0° W - 32.1° T (D)
