ELEMENTS OF DESIGN, Fig. B
The lid
Blender jar 700 ml.
Cross blade set with 4 knives
Device’s body Energy Bullet
Plunger for juicer.
Flat blade set with 2 knives
Small cup 280 ml
Large cup 500 ml
Mugs 480 ml
Measuring cup
Comfort-drinking ring
Shaker top
Storage lid
Filter for juicer
The blades are very sharp, be careful.
APPLYING OF MULTI-BLENDER
ENERGY BULLET, Fig. С.
Order of operation. Fig. С-1.
1. Place the Multi-Blender Energy Bullet on a solid,
at, non-slip surface. Fill the large cup with the
ingredients. Make sure that the load level does not
exceed the maximum marks.
2. Fig. С-2. Choose one of the removable blades
provided: a at blade with 2 knives is recommended
to use for solid foods (coee, spices, nuts and etc.), a
cross blades with 4 knives use for soft vegetables and
fruits for more thorough chopping. Place the blade
on the ingredients bowl, turn the mixing bowl upside
down, align the arrows on the base and place the
bowl in the blender.
3. Plug in the device to the network with the appropriate
characteristics. For quick chopping, press on the
large cup, small cup or juicer and keep it pressed.
To stop the grinding process, release the mixing cup
and keep it from falling. To lock the cup in the hand
blender, press and turn it clockwise. To stop, turn the
bowl counterclockwise to stop (keep it from falling).
Juicer assembly. Fig. С-3.
1. Place the cross blade with 4 knives on the bottom of
the juicer.
2. Insert the lter into the center of the jug of the juicer,
making sure that the ribs are in the troughs inside
the jug.
3. Cover the jug and adjust spill on the spout. Make
sure, the cover is tight and the lter is installed
correctly.
Operation juicer Energy Bullet.
1. Select the juice ingredients, they should be the right
size in the lter of the juicer, put them in the jug for
squeezing.
2. Remove the top glass cover, place the glass on
the base of the juicer, press the blender and turn it
clockwise to turn on automatic mode. Blades clogging
could be result from engine damage, make sure the
engine ran before you put the ingredients in the juicer.
3. Add ingredients through the hole in the center of the
juicer. Press the ingredients against the blade with a
plunger. Juice will form in the blender jar around the
lter.
4. Pour juice into the mugs from the blender jar, after
removing the lter. Be careful to keep the esh
separate from the juice.
NOTE:
1. If the ingredients stick to the walls of the jar during
operation, use the plunger.
2. If the blades get stuck in automatic mode, unplug the
blender immediately. Sometimes solid ingredients
get stuck in the blades and need to be cleaned
immediately before proceeding. If an obstacle occurs
during the blender operation in the movement of the
blades, engine damage can occur.
NOTE:
1. Do not operate the appliance longer than 3 minute
each time. If you have not nished blending after 3
minute, switch the appliance o and wait 1 minute
before you continue using it.
2. Products are placed into the cup until the device
is turned on. Make sure that the cup is lled with
products no more than 2/3 of the volume of the jug.
3. It is recommended to peel the products, seeds and
inedible parts before chopping / mixing.
4. It is not recommended to use this blender for products
such as frozen vegetables / fruits, coconut, cereals
and more.
4. Place the jug on the blender base.
Before rst use, make one preparation cycle without
ingredients, add water into the glass cup. After that,
wipe the body of the device with a dry soft cloth. Wash
the cup, lid, pusher, measuring cup and stainless steel
knives with warm water and detergent.
Before assembling and disassembling the device,
make sure it is unplugged.
The device is equipped with overload and
overheating protection. If there is an overload
or an overheating, the device will automatically
stop. Unplug the device. Let it cool for 45
minutes. After that, you can continue using
the device.
Maximum time of continues use of the blender
is 2 minutes, after that you need to turn o the
device and let it cool for 3 minutes. Do not use
the device without water or ingredients.
When grinding hard products, do not use the
device more than for 1 minute. Let the device
cool for at least 5 minutes.
PRODUCT SET
Device’s body Multi-Blender Energy Bullet ............1 pcs.
Flat blade set with 2 knives ...................................1 pcs.
Cross blade set with 4 knives ................................1 pcs.
Large cup 500 ml ................................................... 1 pcs.
Small cup 280 ml ...................................................1 pcs.
Shaker tops ...........................................................2 pcs.
Mugs 480 ml ..........................................................2 pcs.
Comfort-drinking ring .............................................2 pcs.
Storage lid .............................................................2 pcs.
Blender jar set 700 ml............................................1 pcs.
Plunger ..................................................................1 pcs.
Instruction manual .................................................1 pcs.
Warranty card ........................................................1 pcs.
PREPARATION RECOMMENDATIONS
Type of blades.
General recommendations on the volume of ingredients, the type of bowl and blades.
Type load Cross blade set with 4 blades Flat 2 blades
Fruits and water or vegetables and
water
YES NO
Meat or Beef YES NO
Coee bean or Grain NO
YES
Type load Type of bowl and blades Max capacity Max time of working
Fruits or vegetables with
water or milk
Bowl 500 ml or mags 480
ml and cross blade set with
4 blades
180 g dry product
+ 320 ml liquid
2 min with a break of 1
min.
10 cycles max
Meat or Beef
Bowl 500 ml and cross
blade set with 4 blades
350 g product
15 sec with a break of 2
min.
3 cycles max
Coee bean or grain
Small cup 280 ml and at
blade with 2 blades
100 g dry product
30 sec with a break of 1
min.
3 cycles max
CLEANING AND MAINTENANCE, Fig. D
• Wash the cup, lid, pusher, measuring cup
and stainless steel knives with warm water
and detergent.
• Wipe the body with a damp cloth. Never
immerse it in water because of the danger
of electric shock.
• Thoroughly dry all parts.
The knives are very sharp, be careful.
Operation
Maximum capacity or weight
of the ingredients
Time, min Note
Pour warm water into the
cup and add detergent
500 ml
3
min.
After washing, completely disassemble the
cup’s base, rinse and dry the knives. Do not
use harsh detergents.
CLEANING THE BLENDER’S CUP
