www.routerboard.com 1 2-Jul-2012

RouterBOARD+750UP+

Quick&Setup&Guide&and&Warranty&Information&

The$RB750UP$is$a$router$with$five$Ethernet$ports.$It$has$one$USB$2.0$port,$and$supports$PoE$power$output$to$$

ports$2?5$(500mA$maximum$per$port).$

First&use&

• Connect$your$WAN$cable$to$port$1,$$

and$LAN$computers$to$ports$2?5$

• Set$LAN$computer$IP$configuration$to$automatic$(DHCP)$

• RB750UP$Default$IP$address$from$LAN$is$192.168.88.1$

Powering&

The$board$accepts$powering$from$the$power$jack$or$from$the$

first$Ethernet$port$(P ass ive$Po E ):$

• direct?input$pow er$jack$(5.5mm$outside$and$2mm$inside,$female,$pin$positive$plug)$accepts$8?28V$DC$

• first$Ethernet$port$a cce pts $pas sive$P ow e r$ove r$Eth ern et$acc ep ts$8?28V$DC$

Normally$the$power$consumption$of$this$device$is$2.4W,$under$maximum$load$?$3.6W$

Power&output&

This$RouterBOARD$device$can$supply$PoE$powering$to$external$devices$from$its$Ethernet$ports.$This$is$convenient$as$

you$don't$need$any$additional$PoE$injectors$to$power$other$devices.$This$feature$is$indicated$by$the$letter$“P”$in$the$

device$model$name.$The$output$Voltage$will$be$the $sam e$as $inpu t$Vo ltage ,$and $this$featu re$w ill$have$to $be$e na bled $

on$the$specific$ports$in$RouterOS$software.$By$default$it$is$disabled.$Maximum$power$output$of$each$ethernet$port$in$

this$mode$is$500 m A.$Once$Power$Output$is$enabled$in$RouterOS,$the$Ethernet$LED$light$turns$from$Green,$to$Red.$

Read$LED$means$the$port$is$currently$providing$PoE$power.$$

Booting&process&

This$device$doesn't$com e $f itt e d $with$a$Se ria l $P o r t$c o nnector,$s o $ in it ia l$c onnectio n $ h a s $to$be$done$via$the $Etherne t$

cable,$using$the$MikroTik$Winbox$utility.$Winbox$should$be$used$to$connect$to$the$default$IP$address$of$192.168.88.1+

with$the$username$admin$and$no$password.$

In$case$IP $co nnection $is$n o t $av a ilable,$Winb o x$c a n $a lso $b e $u s ed $t o $co n n e c t$to$the$MA C $a d d re s s$o f$t h e $d ev ice .$More$

informa tio n $h e re :$http://wiki.mikrotik.com/wiki/First_time_startup$

In$case$you$wish$to$boot$the$device$from$network,$for$example$to$use$MikroTik$Netinstall,$hold$the$RESET$button$of$

the$device$wh en $starting $it$until$the$LE D$light$tu rns$off,$an d$R B7 50 $will$start$to$loo k$for$Ne tinsta ll$servers.$

Extension&Slots&and&Ports&

• Five$individual$Ethernet$ports,$supporting$automatic$cross/straight$cable$correction$(Auto$MDI/X),$so$you$can$

use$either$straight$or$cross?over$cables$for$connecting$to$other$network$devices.$The$Ethernet$port$accepts$

8?28$V$DC$powering$from$a$passive$PoE$injector,$12 V $o r $more$is$rec o mmen d e d $to$comp e n sa t e $fo r $lo s s$i n $

cables.$
