1 To deplete the rechargeable battery of any charge, remove the

handle from the charger, turn on the Philips Sonicare and let it run

until it stops. Repeat this step until you can no longer turn on the

Philips Sonicare.

2 Remove and discard the brush head. Cover the entire handle with

a towel or cloth (Fig. 22).

3 Hold the top of the handle with one hand and strike the handle

housing 0.5 inch above the bottom end. Strike firmly with a

hammer on all 4 sides to eject the end cap (Fig. 23).

Note: You may have to hit on the end several times to break the

internal snap connections.

4 Remove the end cap from the toothbrush handle. If the end cap

does not release easily from the housing, repeat step 3 until the

end cap is released (Fig. 24).

5 Holding the handle upside down, press the shaft down on a hard

surface. If the internal components do not easily release from the

housing, repeat step 3 until the internal components are released

(Fig. 25).

6 Remove the rubber battery cover.

7 Wedge the screwdriver between the battery and the black frame

at the bottom of the internal components. Then pry the

screwdriver away from the battery to break the bottom of the

black frame (Fig. 26).

8 Insert the screwdriver between the bottom of the battery and the

black frame to break the metal tab connecting the battery to the

green printed circuit board. This will release the bottom end of the

battery from the frame (Fig. 27).

9 Grab the battery and pull it away from the internal components to

break the second metal battery tab (Fig. 28).

Caution: Be aware of the sharp edges of the battery tabs so as to

avoid injury to your fingers.

10 Cover the battery contacts with tape to prevent any electrical short

from residual battery charge. The rechargeable battery can now be

recycled and the rest of the product discarded appropriately (Fig.

29).
