14
Technical data TS 75 EBQ/ TS 75 EQ
Power 1600 W
(110 V-Version 13 A)
Speed (idling) 1350 - 3550 rpm
Inclination 0° - 47°
Cutting depth at 0° 0 – 75 mm
Cutting depth at 45° 0 – 56 mm
Saw blade dimensions 210x2.4x30 mm
Weight 6.2 kg
Degree of protection
/II
The specifi ed illustrations can be found at the
beginning of the operating instructions.
Symbols
Warning of general danger
Manual, read the instructions.
Wear ear protection!
Wear protective goggles.
1 Use for intended purpose
These machines are intended to be used for
sawing wood, wood-like materials, plaster and
cement-bonded fibre materials, and plastics.
With the special saw blades for aluminium offered
by Festool, these machines can also be used for
sawing aluminium.
Only saw blades with the following specifi cations
must be used: saw blade diameter of 210 mm;
cutting width of 2.4 mm to 2.6 mm; toolholder
diameter of 30 mm; blade core thickness of max.
1.8 mm; suitable for speeds of up to 5000 rpm.
Do not use any abrasive wheel.
Festool electric power tools should only be in-
stalled in work benches specially designed by Fes-
tool. The electric power tool may become unsafe
and cause serious accident if installed in benches
from other manufacturers or self-manufactured
work benches.
The user is liable for damage and injury
resulting from incorrect usage!
2 Safety instructions
2.1 General safety rules
WARNING! Read all safety warnings and
all instructions.
Failure to follow the warnings and instructions
may result in electric shock, fi re and/or serious
injury.
Save all warnings and instructions for future
reference.
The term „power tool“ in the warnings refers
to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
2.2 Tool-specifi c safety rules
1) Cutting procedures
a)
DANGER: Keep hands away from cutting
area and the blade. Keep your second hand
on auxiliary handle, or motor housing. If both
hands are holding the saw, they cannot be cut
by the blade.
b) Do not reach underneath the workpiece. The
guard cannot protect you from the blade below
the workpiece.
c) Adjust the cutting depth to the thickness of the
workpiece. Less than a full tooth of the blade
teeth should be visible below the workpiece.
d) Never hold piece being cut in your hands or
across your leg. Secure the workpiece to a
stable platform. It is important to support
the work properly to minimize body exposure,
blade binding, or loss of control.
e) Hold power tool by insulated gripping sur-
faces when performing an operation where
the cutting tool may contact hidden wiring
or its own cord. Contact with a „live“ wire will
also make exposed metal parts of the power
tool „live“ and shock the operator.
f) When ripping always use a rip fence or straight
edge guide. This improves the accuracy of cut
and reduces the chance of blade binding.
g) Always use blades with correct size and shape
(diamond versus round) of arbour holes.
Blades that do not match the mounting hard-
ware of the saw will run eccentrically, causing
loss of control.
h) Never use damaged or incorrect blade wash-
ers or bolt. The blade washers and bolt where
specially designed for your saw, for optimum
performance and safety of operation.
i) Wear suitable protection such as
ear protection, safety goggles, a
dust mask for work which gener-
ates dust, and protective gloves
when working with raw materials
and when changing tools.
Circular saw TS 75 EBQ/ TS 75 EQ
