- 25 -

1. PRODUCT ACCESSORIES

The product is packed together with service instructions and list of servicing organisations. For non-

pressure connection, no safety valve is used; the function of it is performed by a non-pressure combination

faucet. The package contains anchors and fasteners to mount the heater.

2. MESSAGE FOR CUSTOMERS

The electric heater is designed for preparation of hot water in households, cottages and various welfare

facilities. It allows installation of only one hot water consumption point. Its benefit is that it heats up water

by power in an unlimited all-day time range. The time of heating service water to the recommended

temperature of 60°C is about 9 and 18 minutes, depending on the volume.

3. TECHNICAL DESCRIPTION

BTO 5, 10 UP– non-pressure heater of 5 (10) l capacity located above the supply point

BTO 5, 10 IN– non-pressure heater of 5 (10) l capacity located underneath the supply point

The heater tank is plastic for non-pressure connection, the electric heating element is copper. The heater

tank is provided with a valuable polyurethane insulation, all is stored in an upper plastic container. Electric

wiring is placed in the bottom (upper) part of the heater, under the removable guard of the heater.

Temperature of water can be set by a thermostat within the range between 5°C and 75°C, using the

symbols on the thermostat selector button (read more in chapter 13). Cold water inflow is indicated with a

blue ring, hot water outflow is indicated with a red ring.

It is recommended to use the product in indoor environment with air temperatures from

+2°C to 45°C and a relative humidity up to 80%.
