4. GENERAL TECHNICAL DATA

5. OPERATING ACTIVITY

After the heater is connected to electric network, the heating element starts heating water. The element is

turned on and off by a thermostat.

Thermostat can be set as per your need within the range from 5°C to 75°C. We recommend setting service

water to max temperature of 55°C. This temperature ensures the optimal operation of the heater. After

reaching the temperature set, the thermostat switches off the electric circuit and discontinues water

heating. The control light signals if the element is in operation (light is on) or if it is off (the light goes out).

In case of longer operation without using the heated volume the thermostat has to be

set to position 9°C (set the “snowflake” symbol on the thermostat button) to avoid its

freezing.

6. WALL MOUNTING

Prior to mounting check the loading capacity of the wall. If needed, reinforce it. Mount the water heater in

vertical position only. The fastening screws must have guaranteed spacing of 140 mm. Mounting

dimensions are specified on Fig. 1.

Type

BTO 5 IN/UP

BTO 10 IN/UP

Capacity

Rated pressure

MPa

Weight

3,5

Power in put

2000

Time of rating from 10° to 60°C

min

Electric connection

1 PE-N

230V/50HZ

1 PE-N

230V/50HZ

IP Protection

IP 24

Heat losses /energy efficiency class

kWh/24h

0,32

0,4
