2. Description

The tool is a manual pneumatic tool designed for drilling and reaming holes up to 10 mm diameter in

the steels of the average strength as well as nonferrous metals, plastic and wood.

Caution:

If revealing any faults immediately discontinue the operation.

When connecting the pneumatic tool to the compressor hose always block the air escape

cock.

Always follow the safety rules when using the compressed air.

3s. Technical pecifications

The manufacturer reserves himself the right to make the manual's content or function

change without any preliminary notification of the users.

tools

4. Connection and operation

It is necessary to re-activate the tool before the operation start. To re-activate the tool pour the pure

paraffin through the inlet connecting pipe when the trigger is open, then blow the tool through with

the dry compressed air. Repeat it 2 or 3 times.

The system of the compressed air lead-in to the tool is in the below diagram.

- The system of the compressed air lead-in to the tool is in the below diagram.If the lubricator is not

used during the operation it is necessary to pour 5-10 ml of the machine oil as per specification

SAE#10 or its analogue into the inlet connecting pipe of the tool every operating hour.

- Check the thread connection tightening firmness on the housing of the tool periodically during the

maintenance their slackening is not allowed.

- Check the tool position relative to the axis of the hole processed during the operation.

Nonobservance of the coaxiality causes the vibration strengthening, efficiency and the tool

resource decrease.

–

MODEL 100103 100115 100116

Drill Max size, mm 10 10 10

No load spindle rotation speed, rpm 1800 1800 2500

Inlet diameter, inch

Total air consumption, l/min 566 566 623

Average air consumption at work cycle min, l/min 142 142 156

Operation pressure, bar 6,3 6,3 6,3

Weight, kg 1,1 1,1 0,9

Air conductive hose diameter recommended, mm 6х8 6х8 6х8
