Installing upgrades > 148
4. Observing safety rules for lifting and, using locating guides, place MFP on top of the
tray/cabinet assembly.
5. Loosen eight screws (6) (four on left side and four on right side).
WARNING!
This product is heavy; a minimum of three people are required to
lift it safely.
5
4
6
6
