Specifications > 49
S
PECIFICATIONS
ITEM SPECIFICATION
Model No. D22511B
Print method Impact dot matrix
Print head 24 pins, 0.2 mm (0.0079 in) diameter
Dimensions 349mm(W) x 290mm(D) x 180mm(H)
Weight 4 kg
Power rating
Voltage
Frequency
220 – 240V ± 10%
50/60 Hz ± 2Hz
Power consumption
Operation
Powersave mode
Typ. 45W (ISO/IEC1056/Letter)
1.7W
Environmental conditions
Operating
Storage
5°C – 40°C, 30% – 85% RH (Testing condition for print
precision: 15°C – 30°C, 40% – 70%RH)
-20°C – 60°C, 0% – 95% RH
When the printer is stored, it should be in its original
packaging, with no moisture formation.
Noise level The acoustic noise of this product is less than 58dB (A)
as measured in accordance with EN ISO 7779.
