SWIVEL BELT CLIP
■ Optional MB-86 contents
Qty.
q Belt clip ………………………………………………………………… 1
w Base clip ……………………………………………………………… 1
e Screws ………………………………………………………………… 2
■ Attaching
q Attach the base clip to the back of the transceiver.
w Clip the belt clip to a part of your belt and insert the base clip into
the belt clip.
Belt clip
Supplied screws
Base clip
