PANEL DESCRIPTION

WIDE/NARROW KEY

Push to toggle the IF bandwidth between wide and narrow.

• The wide passband width can be selected from 25.0 or 20.0 kHz

using the CS-F3020/F5020 cloning software. (PMR operation

only) Ask your dealer for details.

DTMF AUTODIAL KEY

➥ Push to enter the DTMF channel selection mode. And

then select the desired DTMF channel using [CH Up]/

[CH Down].

➥ After selecting the DTMF channel, push again to transmit

the selected DTMF code.

RE-DIAL KEY

Push to transmit the last-transmitted DTMF code.

• TX memories are cleared after turning the transceiver OFF.

CALL KEYS

Push to transmit a 2/5-tone ID code.

• Call transmission is necessary before calling another station

depending on your signalling system.

• [Call A] and/or [Call B] may be available when your system

employs selective ‘Individual/Group’ calls. Ask your dealer which

call is assigned to each key.

EMERGENCY KEY

Push and hold this for speciﬁed period to transmit an emer-

gency call.

• The emergency call transmits with beeps; the display does not

change.

• The transceiver can transmit an emergency call with no beep emis-

sion and LCD indication change depending on the pre-setting. Ask

your dealer for details.

• If you want to cancel the emergency call, push and hold the key

again before transmitting the call.

• The emergency call is transmitted one time only or repeatedly until

receiving a control code, depending on the pre-setting.

SURVEILLANCE KEY

Push to turn the surveillance function ON or OFF.

When this function is turned ON, the beep is not emitted and

the LCD backlight does not light when a signal is received or

a key is pushed, etc.

SIREN

Push to emit a siren.

TX CODE ENTER KEY (PMR operation only)

Push to enter the TX code edit mode directly.

Then set the desired digit using [CH Up]/[CH Down]. (p. 10)
