Icom IC-F610 [19/24] Connection and maintenance
![Icom IC-F610 [19/24] Connection and maintenance](/views2/1074569/page19/bg13.png)
16
4
CONNECTION AND MAINTENANCE
D Mounting the transceiver
The universal mounting bracket supplied with your transceiv-
er allows overhead mounting.
•Mount the transceiver securely with the 4 supplied screws
to a thick surface which can support more than 1.5 kg.
Flat washer
Spring washer
When using
self-tapping screws
IC-F510F520_F610F620-1.qxd 02.3.12 2:51 PM Page s (1,1)
