Front Panel Storage
8
Installation Chart
05
06
Schrauen Sie ein
Visser la vis
Asegurar con tornillos
Fissare con viti
Secure with screws
Закрутить винты
나사를 채웁니다
ล็อคสกรู
鎖上螺絲固定
锁上螺丝固定
ねじをしめる
Machen Sie den Vorderrahmen
zu
Fermer la lunette avant
Cerrar el marco frontal
Chiudere il frontalino
Close drive door
Закрыть панель
프레임을 닫습니다
ปิดกรอบด้านหน้า
關上硬碟門
关上硬盘门
フロントフレームをオフにし
ます
