Front Panel Storage
6
Installation Chart
have all components collected
check that all components do not have compatibility problems with each other or with the case
if possible, assemble the components outside the case first to make sure they are working
keep the motherboard manual ready for reference during installation
prepare a Phillips screwdriver.
1
2
3
4
5
Before you begin, please make sure that you
01
02
Entfernen Sie dieVorderrahmen
Ouvrir la lunette avant
Abrir el marco frontal
Aprire il frontalino
Open drive door
Открыть внешнюю панель
앞쪽 프레임을 엽니다
เปิดกรอบด้านหน้า
打開硬碟門
打开硬盘门
フロントフレームをオンにし
ます
Legen Sie die Festplatte ein
Installer le disque dur
Instalar la unidad de disco duro
Installare i dischi
Install drive
Установить жесткий диск
하드디스크를 장착합니다
ติดตั้งฮาร์ดดิสก์
安裝硬碟
安装硬盘
ハードディスクをインストール
します
