![Icom IC-F3061 [30/36] Options](/views2/1074599/page30/bg1e.png)
26
9
OPTIONS
D BATTERY PACK
D CHARGERS
•BC-119N
DESKTOP CHARGER
+ AD-106
CHARGER ADAPTER
+ BC-145
AC ADAPTER
For rapid charging of battery packs. An AC adapter is sup-
plied with the charger depending on versions. Charging
time: approx. 2 hours when BP-231 is attached.
•BC-121N
MULTI
-
CHARGER
+ AD-106
CHARGER ADAPTER
(6 pcs.)
+ BC-157
AC ADAPTER
For rapid charging of up to 6 battery packs (six AD-106’s are
required) simultaneously. An AC adapter should be pur-
chased separately. Charging time: approx. 2 hours when
BP-231 is attached.
•BC-160
DESKTOP CHARGER
+ BC-145
AC ADAPTER
For rapid charging of battery packs. An AC adapter is sup-
plied with the charger depending on versions. Charging
time: approx. 2 hours when BP-231 is attached.
D BELT CLIPS
•MB-93
SWIVEL BELT CLIP
•MB-94
BELT CLIP
Exclusive alligator-type belt clip. The same as supplied with
the transceiver.
•MB-96N/96F
LEATHER BELT HANGER
D OPTIONAL UNITS
•UT-96R 2/5
TONE UNIT
•UT-109R /UT-110R
SCRAMBLER UNITS
Non-rolling type (UT-109R)/Rolling type (UT-110R) voice
scrambler unit provides higher communication security.
•UT-119
DIGITAL MODULATOR
/
DEMODULATOR UNIT
Provides 6.25/12.5 kHz narrow bandwidth digital mode
operation.
D DC CABLES
•CP-17L
CIGARETTE LIGHTER CABLE
Allows charging of the battery pack through a 12 V cigarette
lighter socket. (For BC-119N)
•OPC-515L/OPC-656
DC POWER CABLES
Allows charging of the battery pack using a 13.8 V power
source instead of the AC adapter.
OPC-515L: For BC-119N
OPC-656 : For BC-121N
7.4 V
7.4 V
1150 mAh
2000 mAh
Battery case for AAA
(LR03) × 6 alkaline
Battery pack
BP-231
BP-232
BP-240
Voltage Capacity Battery life
8 hrs.
15 hrs.
–
*
1
*
1
*
2
Operating periods are calculated under the following conditions;
TX : RX : standby = 5 : 5 : 90
*
2
Operating periods depends on the alkaline cells used.
