SilverStone FS208 [10/24] Manual fs204 t086 _fs208 t088 _fs212 t089 v1 8
![SilverStone SST-FS212B [10/24] Manual fs204 t086 _fs208 t088 _fs212 t089 v1 8](/views2/1746011/page10/bga.png)
Front Panel Storage
8
Installation Chart
05
06
Bauen Sie die Festplatte ins
Gehäuse ein
Installer le châssis du disque
dans la case
Instalar el chasis de disco en la
carcasa
Installare il telaio rigido in caso
Install drive chassis into case
Установить жесткий диск в
корпус ПК
하드디스크를 본체 케이
스에 장착합니다
ติดตั้งฮาร์ดดิสก์เข้ากับตัวเ
คส
放入機殼
放入机箱
ハードディスク固定台を
機械ケース中に入れます
Schließen Sie SATA an die
Leitung an
Connecter SATA et le câble
d’alimentation
Conecta SATA y la cable de
alimentación
Collegare il cavo SATA e
elettricità
Connect SATA and power cable
Соединить SATA с кабелем
питания
SATA와 전원 케이블을
연결합니다
เชื่อมต่อ SATA เข้ากับสา
ยสวิตซ์ไฟ
連接SATA 線與電源線
连接SATA 线与电源线
SATAを電力線と接続し
ます
