ENGLISH
6
Top and front panels
1. VOLUME
- adjust volume level.
2. REMOTE SENSOR
-remote control signal sensor
3. FUNCTION SELECT
- select source of sound MP3/CD,
TAPE or RADIO, also the power off switch.
4. CD BACK ()
CD: - Skip track backwards.
5. PLAY/PAUSE BUTTON ()
- start or pause MP3/CD play
6. STOP BUTTON
- stop CD playback; erase a CD program.
7.
CD NEXT()
CD: - Skip track forwards.
8. BAND SELECTOR (AM FM FM ST.)
- select AM/FM/FM ST. Waveband.
9. STEREO HEADPHONE JACK
- 3.5 mm stereo headphone jack.
10. TELESCOPIC ANTENNA
- to improve FM reception
11. TUNING CONTROL
- select AM/FM/FM ST. Stations.
12. BASS BUTTON
- enhances bass response
13. POWER BUTTON
- Switch the system on or to standby mode.
14. FM STEREO INDICATOR
- show the FM stereo indicator
15. CD DOOR
16. CD DOOR OPEN BUTTON
- press here to open/close the CD door.
17. LCD DISPLAY
- show the AM/FM dial frequency
- show the number of tracks
18. REPEAT BUTTON
- repeat a track CD/MP3 program
19. RANDOM BUTTON
CD: - play CD tracks in random order
20. CASSETTE RECORDER KEYS
PAUSE KEY(- interrupt recording or STOP/
EJECT KEYC
- stop the tape - open
the cassette compartment
F. FWD KEY (-ativance the tape toward the
end).
F. REW KEY (-Rewind the tape toward the
beginning.
PLAYKEY ( ) -start playback
RECORDER () - start recording
21. CASSETTE COMPARTMENT
-put into the cassette
22. AC MAINS
-inlet for power cord
23. BATTERY DOOR
-to open battery compartment.
Power Supply
Using AC Power
1. Check if the power voltage, as shown on the
type plate located on the bottom of the set,
corresponds to your local AC power supply.
If it does not, consult your dealer or service
centre.
2. Connect the power cord to the AC MAINS
inlet and the wall outlet. The power supply
is now connected and ready for use.
3. To switch off completely, unplug the power
cord from the wall outlet.
• Unplug the power cord from the wall
outlet to protect your set during heavy
thunderstorms.
Batteries (not included)
Open the battery compartment and insert
eight batteries, type R-14, UM-2 or C-cells,
(preferably Alkaline) with the correct polarity
as indicated by the + a,,nd - s,,ymbols
inside the compartment.
Batteries contains chemical substances, so
they should be disposed of properly.
Incorrect use of batteries can cause electrolyte
leakage and will corrode the compartment
or cause the batteries to burst. Therefore:
• Do not mix battery types: e.g. alkaline with
carbon Zinc. Only use batteries of the same
type for the set.
• When inserting new batteries, do not try to
mix old batteries with new ones.
• Remove the batteries if the set is not be
used for a long time.
BASIC FUNCTION
RADIO
Switching power on/off: Save energy Whether
you are using mains or battery supply, to avoid
unnecessary energy consumption always adjust
the source selector to off.
For FM, pull out the telescopic antenna. Incline
and turn the antenna. Reduce its length if the
signal is too strong (very close to a transmitter).
For AM, the set is provided with a built-in
antenna so the telescopic antenna is not
needed. Direct the antenna by turning the whole
set.
3479.indd 63479.indd 6 11.04.2006 16:36:1311.04.2006 16:36:13
