• Indoor Unit • FTXP-M
2
• Split - Sky Air • FTXP-M
4
2 Specifications
Standard Accessories : Installation manual; Quantity : 1;
Standard Accessories : Operation manual; Quantity : 1;
Standard Accessories : Infrared remote control; Quantity : 1;
Standard Accessories : AAA dry-cell batteries; Quantity : 2;
Standard Accessories : Remote control holder; Quantity : 1;
Standard Accessories : Mounting plate; Quantity : 1;
Standard Accessories : Titanium apatite deodorizing filter; Quantity : 1;
Standard Accessories : Silver particle filter; Quantity : 1;
Standard Accessories : Indoor unit fixing screws; Quantity : 2;
Sound pressure level Cooling High/Medium/
Low/Silent
operation
dBA 39/33/25/19 40/33/26/19 43/34/27/20 43/39/34/27 45/41/36/30 46/42/37/32
Heating Super high/High/
Medium/Low/
Silent operation
dBA -/39/34/28/21 -/40/34/28/21 -/40/35/29/21 42/38/33/30/- 44/40/35/32/- 45/41/36/33/-
Control systems Infrared remote control ARC480A53
Wired remote control BRC944B2 / BRC073A1 -
Piping connections Liquid OD 6,35
Gas OD 9.50 12.7
Drain 18
Heat insulation Both liquid and gas pipes
Temperature control Microcomputer control
Air direction control Left, right, up and downwards
2-2 Electrical Specifications FTXP20M FTXP25M FTXP35M FTXP50M FTXP60M FTXP71M
Power supply Name - V1
Phase 1~
Frequency Hz 50
Voltage V 220-240
Current Nominal running
current (RLA) - 50Hz
Cooling A 0.19 0.20 0.29 0.32 0.34
Heating A 0.21 0.29 0.34 0.37 0.40
2-1 Technical Specifications FTXP20M FTXP25M FTXP35M FTXP50M FTXP60M FTXP71M
