Daikin FTXP71M2V1B [5/18] Specifications
![Daikin FTXP71M2V1B [5/18] Specifications](/views2/1746710/page5/bg5.png)
3
2
• Split - Sky Air • FTXP-M
3
• Indoor Unit • FTXP-M
2 Specifications
2-1 Technical Specifications FTXP20M FTXP25M FTXP35M FTXP50M FTXP60M FTXP71M
Power input Cooling Nom. kW 0.019 0.020 0.032 0.029 0.032
Heating Nom. kW 0.023 0.032 0.035
Casing Colour White
Dimensions Unit Height/Width/
Depth
mm 286/770/225 295/990/263
Packed unit Height/Width/
Depth
mm 305/830/360 368/1,080/383
Weight Unit kg 8.50 9.00 13.5
Packed unit kg 10.5 11.0 16
Packing Weight kg 2.0 2.5
Heat exchanger Length mm 610 820
Rows Quantity 2
Fin pitch mm 1.40
Stages Quantity 18
Passes Quantity 2.2 6
Tube type ø5 Hi-XB
Fin Type ML fin (Multi louver)
Heat exchanger 2 Length mm - 600 810
Rows Quantity - 1
Fin pitch mm - 1.40
Stages Quantity - 4 8
Air filter Type Removable / washable
Fan Type Cross flow fan
Quantity 1 -
Air flow rate Cooling High m³/min 9.5 9.7 11.5 16.3 16.8
cfm 335.1 343.3 406.1 575 592
Mediu
m
m³/min 7.4 7.7 8.3 14.0 14.4
cfm 262.0 270.2 293.1 493 506
Low m³/min 5.6 5.8 6.3 11.5 11.8
cfm 198.1 205.9 222.5 401 417
Silent
operati
on
m³/min 4.2 4.5 8.3 9.2 10.1
cfm 146.6 159.0 268 330 365
Heating High m³/min 10.4 11.5 17.3 17.9
cfm 368.0 406.1 618 632
Mediu
m
m³/min 8.1 9.0 14.4 15.3
cfm 286.0 317.8 510 540
Low m³/min 6.2 6.4 7.0 11.8 12.4
cfm 217.9 226.0 247.2 421 438
Silent
operati
on
m³/min 5.2 5.3 10.4 11.0
cfm 182.2 287.0 370 387
Fan motor Model MM6K11S20VA MM9E17S21VA
Speed Steps 5 + silent, + auto 5 + sillent, + auto
Cooling High/
Mediu
m/Low/
Silent
operati
on
rpm 1,000/820/660/
530
1,020/840/680/
530
1,140/870/700/
540
1,040/920/790/
600
1,070/940/810/
650
1,070/940/810/
700
Heating High/
Mediu
m/Low/
Silent
operati
on
rpm 1,080/880/710/
620
1,080/880/730/
620
1,140/930/760/
610
1,100/940/810/
730
1,140/990/840/
760
1,170/990/840/
760
Output Rated W 22 46
Sound power level Cooling dBA 55 58 59 60 62
