Icom MR-1000T2 [45/47] Ship s bow direction
![Icom MR-1000T2 [45/47] Ship s bow direction](/views2/1074677/page45/bg2d.png)
Ship’s bow direction
Radius is 6 mm
(
1
⁄4 in)
• EX-2714 Radome template
90.5 mm (3
9
⁄16 in)
90.5 mm (3
9
⁄16 in)
150.5 mm (5
15
⁄16 in)45.5 mm (1
25
⁄32 in)
