6. OPERATING THE CHIMNEY HOOD

Chimney hood is used in ducted and non-ducted kitchens.

6.1. In Ducted Use

In ducted use, extractor fan should be connected to an air outlet to

send the air out. In order to use your chimney hood efciently, make sure

length of the pipe system between the chimney hood and the air outlet

should be short. Your product has been manufactured suitable for ducted

and non-ducted use.

6.2. Round Charcoal Filter

In kitchens with no duct, a round charcoal lter should be reintroduced

the clean air into the kitchen. You can obtain the round lter from your

service or dealer.

6.3. Use Of Charcoal Filter

• Our products allow the installation of charcoal lter.

• Regardless of use of charcoal lters or not, grease lters should be

installed on the product. Do not use your product without grease

lter.

• Use of charcoal lteris as follows.

• Cut off the device power before replacing charcoal lter.

• Charcoal lter is used in the kitchens with no duct therefore should

be replaced in every 3-5 months depending on the frequency of use.

• Charcoal lter should never be washed.

6.4. Installation Of Charcoal Filter

• Charcoal lters are used in the kitchens with no duct.

• Charcoal lters are installed onto both sides of the fan as shown in

Figure 10 by turning 10 degrees clock-wise.

• When uninstalling, reverse the same procedure.

6.5. Use Of Aluminum Cartridge Filter

Aluminum cartridge lter holds dust and grease in the air. Chimney

hoodshould never be used without aluminum cartridge lter. (Figure 11)

Installing Position

Figure 10

Figure 11
