Philips FC9122 [7/84] English

◗ To adjust the nozzle to the type of floor and the area to be cleaned, put your foot on one of

the indicated spots on the nozzle and then turn the tube until the nozzle is in the required

position (fig. 6).

1 With the nozzle positioned breadthwise and the brush strip folded out, you can clean large

hard floor areas.Turn the tube until the brush strip pops out of the nozzle housing and the

nozzle is positioned breadthwise (fig. 7).

2 With the nozzle positioned lengthwise and the brush strip folded out, you can vacuum clean

small hard floor areas.Turn the tube 90 degrees anticlockwise until the nozzle is positioned

lengthwise with the brush strip still folded out of the nozzle housing (fig. 8).

3 With the nozzle positioned breadthwise and the brush strip folded in, you can vacuum clean

large soft floor areas.Turn the tube 90 degrees anticlockwise again to position the nozzle

breadthwise and to make the brush strip disappear into the nozzle housing (fig. 9).

4 With the nozzle positioned lengthwise and the brush strip folded in, you can vacuum clean

small soft floor areas.Turn the tube 90 degrees anticlockwise again until the nozzle is

positioned lengthwise with the brush strip still folded in (fig. 10).

Crevice tool, small nozzle and small brush

1 Connect the crevice tool, the small nozzle or the small brush directly to the handgrip or to

the tube (fig. 11).

Accessory holder

1 The accessory holder can simply be snapped onto the handgrip (fig. 12).

◗ There are two ways to store accessories in the accessory holder.

◗ The crevice tool and small nozzle can be stored in the accessory holder by pushing them

into the holder.To detach them, pull them out of the holder (fig. 13).

◗ Please note the way in which the small nozzle must be placed in the accessory holder.

◗ Instead of the small nozzle, the small brush can be stored in the accessory holder by pushing

it into the holder.To detach it, pull it out of the holder (fig. 14).

Active Fragrance Control (specific types only)

The scent granules have been specially developed for use in your Philips vacuum cleaner. Only use

the s-fresh` scent granules from Philips in your vacuum cleaner.

If the vacuum cleaner is equipped with Active Fragrance Control, keep it out of the reach of

children. Don't let children play with the appliance. Store the vacuum cleaner in a locked

cupboard if there are small children in the house.

These granules are not edible.

In case of eye contact, flush immediately with plenty of water.

Filling the cartridge

1 Place your thumb and index finger on the sides of the cartridge. Remove the cartridge from

the holder by pressing on the disc (fig. 15).

2 Remove the cap of the cartridge by pulling while applying pressure on the small pressing

points (fig. 16).

3 Open the package at the small opening at the top.

4 Fill the cartridge with the content of one whole package of scent granules.

ENGLISH 7
