39
Fig.
6
During short pauses in vacuuming, the appliance can
be left standing anywhere in the room. To do this, tilt
the vacuum cleaner forwards slightly in the direction
of the nozzle.
!
Caution: When the appliance is left standing, it
must be switched off because, if the brush is
turning while the appliance is standing still, it could
cause damage to the floor covering.
Using the hand-held cordless vacuum
cleaner
Fig.
7
Unlock the hand-held cordless vacuum cleaner by
pressing the release button and remove it from the
hand-held vacuum cleaner.
Crevice nozzle
For vacuuming crevices and corners, etc.
Fig.
8
Insert the crevice nozzle into the air intake opening
of the cordless vacuum cleaner, as illustrated.
Charging the hand-held cordless vacuum cleaner
Fig.
9
To charge the hand-held cordless vacuum cleaner,
insert it into the hand-held vacuum cleaner and lock
into place. Make sure that it is seated correctly.
After using the appliance
Fig.
10
Switch off the appliance after vacuuming.
Emptying the dust container
In order to achieve the best possible vacuuming re-
sults, the dust container should be emptied after every
use.
Fig.
11
Remove the hand-held cordless vacuum cleaner
from the hand-held vacuum cleaner.
Fig.
7
Using the release button, unlock the dust container
and remove it from the motor unit.
Fig.
12
Use the handle to remove the motor protection filter
and foam filter from the dust container.
Empty the dust container.
Cleaning the filter
Fig.
13
Unlock the dust container. Use the handle to remove
the motor protection filter and foam filter from the
dust container. (
Fig.
11
+ Fig.
12
)
Clean the motor protection filter and foam filter by
tapping out the dirt.
If there are heavy deposits of dirt, the filter and dust
container can be washed out.
Then wipe out the dust container with a dry cloth;
allow the filter to dry completely before re-inserting
it.
Fig.
14
a) Insert the motor protection filter and foam filter into
the dust container.
b) Fit the dust container onto the motor unit and lock it
into place.
New filters can be obtained from our after-sales ser-
vice, if required.
Cleaning the floor nozzle
Before carrying out any maintenance, switch off the
vacuum cleaner and disconnect it from the charging
cable.
Fig.
15
Use the release button to release the brush roller
and pull it sideways out of the floor nozzle.
Using the groove provided, cut through threads and
hairs wound round the rollers with scissors.
Push the brush roller in sideways along the guide rod
in the floor tool and lock in place using the release
button.
!
Caution: The floor nozzle must only be put into
operation with the brush roller fitted.
!
Caution:
Floor nozzles are subject to a certain amount of
wear, depending on the type of hard floors you have
(e.g. rough, rustic tiles). You must therefore check
the underside of the floor tool at regular intervals.
Worn undersides of floor nozzles may have sharp
edges that can damage delicate hard floors, such as
parquet or linoleum. The manufacturer does not ac-
cept any responsibility for damage caused by worn
floor tools.
Care
Before cleaning the hand-held vacuum cleaner or hand-
held cordless vacuum cleaner, it must be switched off
and disconnected from the charging cable. They can be
cleaned using a standard commercially-available plas-
tic cleaner.
!
Caution: Do not use abrasive materials, glass-
cleaning agents or all-purpose cleaning products.
Never immerse the vacuum cleaner in water.
Subject to technical modifications.
