Metabo P 5500 M [6/8] Danger of freezing

ENGLISH

• Check suction and pressure lines for

leakages.

• If the pump capacity lessens clean

suction strainer and filter cartridge (if

installed), replace if necessary.

7.2 Danger of freezing



Caution!

Frost damages the pump and

accessories, as both always contain

water!

• When there is danger of freezing,

dismount equipment and accesso-

ries and store at a freeze-proof loca-

tion (see below).

7.3 Equipment dismounting

and storing

1. Switch equipment OFF and unplug.

2. Open pressure line (open tap or

spray nozzle) and drain water com-

pletely.

3. Drain pump completely; to do so

remove the drain plug from the

pump

4. Disconnect suction and pressure

lines from the equipment.

5. Store equipment in a frost-free

space (at least 5 °C).



Danger!

Prior to all servicing:

− Switch Off.

− Unplug.

− Ensure that pressure is relieved

from equipment and connected

accessories.

8.1 Fault finding

Pump does not run:

• No mains voltage.

− Check cables, plug, outlet and

mains fuse.

• Mains voltage too low.

− Use only extension cables with

sufficient lead cross section (see

"Technical Specifications").

• Motor overheated, motor protection

relay tripped.

− After cooling off the pump will

switch ON again.

− Ensure sufficient ventilation, keep

vent slots clear.

− Observe max. temperature of the

pumped medium.

• Motor hums but does not start.

− With the motor switched OFF, put

screwdriver or similar through the

fan cover's vent slots and turn the

fan.

• Pump blocked or out of order.

− Disassemble pump and clean.

− Clean diffusor, replace if neces-

sary.

− Clean impeller, replace if neces-

sary.

Pump does not prime correctly or

runs very noisily:

• Lack of water.

− Ensure there is a sufficient water

supply.

• Suction line leaky.

− Seal suction line, tighten screw

fittings.

• Suction head too high.

− Observe max. suction head.

− Install check valve, fill suction line

with water.

• Suction strainer (accessory)

blocked.

− Clean, replace if necessary.

• Check valve (accessory) blocked.

− Clean, replace if necessary.

• Water leaks between motor and

pump, Duocone seal worn.

− Replace Duocone seal.

• Pump blocked or out of order.

− see above.

Pressure too low:

• Suction line leaky or too much suc-

tion head.

− see above.

• Pump blocked or out of order.

− see above.



Danger!

Repairs to electric tools must

only be carried out by a qualified

electrician!

Electric tools in need of repair can be

sent to an authorised service center in

your country. See spare parts list for

address.

Please attach a description of the fault to

the electric tool.

For shipping:

• Drain pump completely (see "Equip-

ment dismounting and storing").

• Ship equipment in original packing,

if possible.

The packaging of the pump can be

100 % recycled.

Worn out power tools and accessories

contain considerable amounts of valua-

ble raw and plastic materials, which can

be recycled.

These instructions are printed on chlo-

rine-free bleached paper.

For this equipment the following acces-

sories are available at specialist dealers.



Note:

Illustrations and stock numbers

can be found at the end of these instruc-

tions.

A Pump Installation Package,

complete with double nipple, check

valve, filter short, washable filter

cartridge, spiral hose assembly

1 m, thread sealing tape.

B Hydromat HM 1,

for automatic starting when water is

drawn and stopping when no water

is drawn, keeps the pump from run-

ning dry.

C Hydrostop,

for automatic stopping when there

is a lack of water, prevents the

pump from running dry.

D Dry-running Stop Switch,

with 10 m cable, keeps the pump

from running dry when pumping

from tank, pool, etc.

E Spiral Hose 1"

1) 1 m assembly, with quick

release screw fitting at both

ends;

2) 4 m, complete with quick

release screw fitting and

strainer with foot valve;

3) 7 m, complete with quick

release screw fitting and

strainer with foot valve.

F Filter, 1" connection, short,

complete with washable plastic fil-

ter cartridge.

G Disposable Filter Cartridge, short,

for mechanical preliminary filtering

of sand.

H Washable Filter cartridge, short,

for mechanical preliminary filtering

of sand, reusable.

I Activated Carbon Filter Cartridge,

short,

for use with chlorous water,

removes odours or discolouring.

J Filter Cartridge Poly, short,

filled with polyphosphate, for calcif-

erous water supplied to water heat-

ers.

K Pipe Nipple 150 mm, 1" male at

both ends, galvanized, to connect

pump and filter.

L Double Nipple, 1" male at boths

ends.

M Check Valve 1" female, prevents

water backflow and pump running

dry.

N Thread Sealing Tape, 12 m roll.

8. Trouble Shooting

9. Repairs

10. Environmental Protection

11. Available Accessories
