Troubleshooting Si10-417
98 Service Diagnosis
Trouble
shooting
Check No.6
Refer to
P.157
P4 : Radiation fin thermistor
J3 : Discharge pipe temperature thermistor
J6 : Outdoor unit heat exchanger temperature thermistor
J8 : Liquid pipe temperature thermistor
J9 : Gas pipe temperature thermistor
H9 : Outdoor air temperature thermistor
Turn on the power again.
Error
displayed again on remote
controller?
NO
YES
YES
YES
NO
Indoor unit
heat exchanger thermistor
functioning?
Connector
or thermistor
disconnected?
NO
NO
YES
Normal?
Check No. 6
Check the thermistor
resistance value.
Check No. 6
Check the indoor unit heat
exchanger thermistor
resistance value in the
heating mode.
Caution
Be sure to turn off power switch before connect or
disconnect connector, or parts damage may be occurred.
(R3043)
Reconnect.
Reconnect.
Replace defective
one(s) of the following
thermistors.
Radiation fin
thermistor
Discharge pipe
temperature
thermistor
Outdoor unit heat
exchanger
temperature
thermistor
Liquid pipe
thermistor
Gas pipe thermistor
Outdoor temperature
thermistor
Replace the following
thermistor.
Indoor unit heat
exchanger
thermistor
Replace the outdoor
unit PCB. (Replace
the indoor unit PCB.)
Si10-417.fm Page 98 Wednesday, September 22, 2004 6:38 PM
