EN
11
5. QUICK USER GUIDE
This washing machine automatically adapts
the level of the water to the type and
quantity of washing. This system gives a
decrease in energy consumption and a
sensible reduction in washing times.
! Turn on the washing machine and select
the required program.
! Adjust the washing temperature if
necessary and press the required "option"
buttons.
! Press the START/PAUSE button to start
washing.
! The message "end" will appear on the
display or the corresponding led will turn
on at the end of the program.
! Turn off the washing machine.
For any type of wash, see the program
table and follow the operating sequence
as indicated.
Water pressure: min 0,05 Mpa / max 0,8 Mpa
Spin r.p.m.: See rating plate.
Power input / Power current fuse amp /
Supply voltage: See rating plate.
6. CONTROLS AND
PROGRAMS
A
B
DCEFGHI
M
L
A
Programme selector with OFF
position
B
START/PAUSE button
C
SPIN SELECTION button
D
TEMPERATURE SELECTION
button
E
DELAY START button
F
STAIN LEVEL button
G
EXTRA RINSE button
H
OPTIONS button
I
DRYING SELECTION button
L
Digital display
M
DOOR LOCKED indicator light
Program selection
DRYING
If you would like the drying cycle to
begin automatically after washing,
select the programme required using
the DRYING SELECTION button.
Or you can finish the wash and then
select the drying programme and
load size.
Wait until the porthole locked light
turns off: about 2 minutes after the
program ends.
