18 19
MH 7 E KH 7 E
........................ 4633 00 01... .................4321 96 01...
.......................... 1500 W............................. 1500 W
............................ 725 W............................... 725 W
............................ 300 min
-1
.......................... 300 min
-1
............................ 300 min
-1
.......................... 300 min
-1
.......................... 2700 min
-1
........................ 2700 min
-1
........................... 10,5 J ............................... 10,5 J
........................... 14.5 J ............................... 14.5 J
.................................. .................................... 45 mm
.................................. .................................... 80 mm
.................................. .................................. 150 mm
.............................. 66 mm .............................. 66 mm
............................. 7,3 kg ............................... 7,3 kg
.................................. .................................... 96 dB (A)
.................................. .................................. 107 dB (A)
.............................. 91 dB (A)
............................ 101 dB (A)
............................ 104 dB (A)
.................................. ..................................11,5 m/s
2
.................................. ................................... 1,5 m/s
2
............................11,5 m/s
2
............................... 9 m/s
2
............................. 1,9 m/s
2
............................ 1,9 m/s
2
ENGLISH
TECHNICAL DATA
Production code..................................................................................
Rated input .........................................................................................
Output .................................................................................................
No-load speed ....................................................................................
Speed under load max. ......................................................................
Rate of percussion under load max. ...................................................
Impact energy per stroke according to EPTA-Procedure 05/2009 ....
Impact energy per stroke (pre 2009) ..................................................
Drilling capacity in concrete ................................................................
Tunnel bit in concrete, bricks and limestone ......................................
Core cutter in concrete, bricks and limestone ....................................
Chuck neck diameter ..........................................................................
Weight according EPTA-Procedure 01/2003 ......................................
Noise Information KH 7 E
Measured values determined according to EN 60 745.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level (Uncertainty K=3dB(A)) ................................
Sound power level (Uncertainty K=3dB(A)) ....................................
Wear ear protectors!
Noise Information MH 7 E
Typically the A-weighted sound pressure level of the
tool is ..................................................................................................
Measured values determined according to 2005/88/EG at the user’s ear.
2005/88/EC: Conformity assessment procedure according to Annex
VI. Notifi ed Body:
VDE Testing and Certifi cation Institute, Merianstr. 28,
63069 Offenbach, Germany
Measured sound power level ..........................................................
Guaranteed sound power level .......................................................
Wear ear protectors!
Vibration information
Vibration total values (triaxial vector sum) determined according to
EN 60745
Hammer-drilling in concrete:
Vibration emission value a
h
.............................................................
Uncertainty K= .................................................................................
Chiselling
Vibration emission value a
h
.............................................................
Uncertainty K= .................................................................................
WARNING! Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric
shock, fi re and/or serious injury.
Save all warnings and instructions for future reference.
ROTARY HAMMER SAFETY WARNINGS
Wear ear protectors when impact drilling. Exposure to noise
can cause hearing loss.
Use auxiliary handle(s), if supplied with the tool. Loss of control
can cause personal injury.
Hold the power tool by insulated gripping surfaces only, when
performing an operation where the cutting accessory may
contact hidden wiring or its own cord. Cutting accessory
contacting a "live" wire may make exposed metal parts of the
power tool "live" and could give the operator an electric shock.
ADDITIONAL SAFETY AND WORKING INSTRUCTIONS
Use protective equipment. Always wear safety glasses when
working with the machine. The use of protective clothing is
recommended, such as dust mask, protective gloves, sturdy
non-slip footwear, helmet and ear defenders.
The dust produced when using this tool may be harmful to health.
Do not inhale the dust. Wear a suitable dust protection mask.
Do not machine any materials that present a danger to health (e.g.
asbestos).
Switch the device off immediately if the insertion tool stalls! Do not
switch the device on again while the insertion tool is stalled, as
doing so could trigger a sudden recoil with a high reactive force.
Determine why the insertion tool stalled and rectify this, paying
heed to the safety instructions.
The possible causes may be:
• it is tilted in the workpiece to be machined
• it has pierced through the material to be machined
• the power tool is overloaded
Do not reach into the machine while it is running.
WARNING
The vibration emission level given in this information sheet has been measured in accordance with a standardised test given in EN 60745
and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for different applications, with
different accessories or poorly maintained, the vibration emission may differ. This may signifi cantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or when it is running
but not actually doing the job. This may signifi cantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the accessories, keep
the hands warm, organisation of work patterns.
ENGLISH
The insertion tool may become hot during use.
WARNING! Danger of burns
• when changing tools
• when setting the device down
Chips and splinters must not be removed while the machine is
running.
Keep mains lead clear from working range of the machine. Always
lead the cable away behind you.
When working in walls ceiling, or fl oor, take care to avoid electric
cables and gas or waterpipes.
Clamp your workpiece with a clamping device. Unclamped
workpieces can cause severe injury and damage.
Always disconnect the plug from the socket before carrying out any
work on the machine.
When working with large drill diameters, the auxiliary handle must
be fastened in a right angle with the main handle (see illustrations,
section "Twisting the handle").
SPECIFIED CONDITIONS OF USE
KH 7 E:
The pneumatic hammer can be universally used for
hammer drilling and chiselling in stone and concrete.
MH 7 E: The hammer can be used for chiselling in stone and
concrete.
Do not use this product in any other way as stated for normal use.
EC-DECLARATION OF CONFORMITY
We declare under our sole responsibility that the product
described under “Technical Data” fulfi lls all the relevant provisions
of the directives 2011/65/EU (RoHs), 2014/30/EU, 2006/42/EC and
the following harmonized standards have been used:
EN 60745-1:2009 + A11:2010
EN 60745-2-6:2010
EN 55014-1:2006 + A1:2009 + A2:2011
EN 55014-2:2014
EN 61000-3-2:2014
EN 61000-3-3:2013
EN 50581:2012
Winnenden, 2016-10-25
Alexander Krug
Managing Director
Authorized to compile the technical fi le
Techtronic Industries GmbH
Max-Eyth-Straße 10
71364 Winnenden
Germany
MAINS CONNECTION
Appliances used at many different locations including wet room
and open air must be connected via a residual current device (FI,
RCD, PRCD) of 30mA or less.
Connect only to single-phase AC current and only to the system
voltage indicated on the rating plate. It is also possible to connect
to sockets without an earthing contact as the design conforms to
safety class II.
Make sure the machine is switched off before plugging in.
This is a device for professional use which may slightly exceed the
guide values for current harmonics when it is connected to the
public low voltage mains supply. You should therefore contact your
energy supply company before you connect the device to the
public low voltage mains supply.
MAINTENANCE
The ventilation slots of the machine must be kept clear at all times.
Important note! If the carbon brushes are worn, in addition to
exchanging the brushes the tool should be sent to after-sales
service. This will ensure long service life and top performance.
If the supply cord of this appliance is damaged, it must only be
replaced by a repair shop appointed by the manufacturer, to avoid
hazardous situations.
Use only AEG accessories and spare parts. Should components
need to be replaced which have not been described, please
contact one of our AEG service agents (see our list of guarantee/
service addresses).
If needed, an exploded view of the tool can be ordered. Please
state the Article No. as well as the machine type printed on the
label and order the drawing at your local service agents or directly
at: Techtronic Industries GmbH, Max-Eyth-Straße 10,
71364 Winnenden, Germany.
SYMBOLS
CAUTION! WARNING! DANGER!
Always disconnect the plug from the socket before
carrying out any work on the machine.
Please read the instructions carefully before
starting the machine.
Accessory - Not included in standard equipment,
available as an accessory.
Do not dispose of electric tools together with
household waste material.
Electric tools and electronic equipment that have
reached the end of their life must be collected
separately and returned to an environmentally
compatible recycling facility.
Check with your local authority or retailer for
recycling advice and collection point.
Class II tool, tool in which protection against
electric shock does not rely on basic insulation
only, but in which additional safety precautions,
such as double insulation or reinforced insulation,
are provided.
There being no provision for protective earthing or
reliance upon installation conditions.
European Conformity Mark
Regulatory Compliance Mark (RCM). Product
meets applicable regulatory requirements.
National mark of conformity Ukraine
EurAsian Conformity Mark.
