PDM20 Series
- 4 -
Notes for Safe Operation
Read this instruction manual thoroughly before installation, operation, maintenance
or inspection of the smart pump drive. In this manual, safe operation are classified as
“WARNING” or “CAUTION”.
SPD: Abbreviation of smart pump drive.
WARNING
Indicate a potentially dangerous situation which, if not avoided, could result in death or
serious injury to personnel.
CAUTION
Indicate a potentially dangerous situation which, if not avoided, could result in minor or
moderate injury and damage to equipment. It may also be used for warning against unsafe
practices.
Even items described as ( CAUTION) may result in a vital accident in some
situations. Please follow these important notes:
Before Installation
WARNING
Do not install or operate any SPD that is damaged or has missing parts. Otherwise, it may
result in equipment damage or harm life.
