Pag. 7
English
19. Place the cup/mug with the drink to be heated under the steam tube (10).
20. Press the toggle steam switch (9) up paying attention that the steamer always stays immerse in the liquid, to avoid
possible hot drink sprays.
21. Press the toggle steam switch (9) down to stop steaming and remove the steam tube (10) from the cup/mug.
22. The steam tube (10) can become extremely hot so make sure to handle it only touching the rubber safety protection.
23. Clean the steam tube (10) accordingly with a normal damp cloth.
Hot water:
24. Check that the tank contains water. ATTENTION: the internal tank has a special floating device that controls the water
level. In case of lack of water, the water missing pilot light (17) comes on automatically and at the same time the sound
allarm buzzes. Please fill the water tank with water (as described under Starting the machine, points 3-5): this will shut
off the pilot light (17) and the buzzer, confirming that the water level is suitable. NB: the water tank must be filled in
with water till the MAX level indicated on the appliance body.
25. Wait till the coffee ready pilot light (4) comes on.
26. Place a mug under the hot water faucet (11) and press the hot water switch (20) up: the pilot light (21) confirms the
starting. Once you get the desired amount of hot water press the switch (20) down to stop dispensing.
27. After having taken hot water, always check that there is still water in the tank and if it is necessary, fill the water tank
as indicated at point 24.
ROUTINE MAINTENANCE AND PRECAUTIONS:
− Clean up the steam tube (10) after every use.
− Use a normal damp cloth to clean the machine.
− Do not leave the machine outdoors.
− Do not immerse the machine in water.
− Use the machine only under adult control and keep it away from children’s reach.
− Do not wash filters and filter holder in the dishwasher.
− During normal functioning some parts of the appliance body can reach high temperatures: please handle with due
caution!
ATTENTION: the machine is equipped with a water tank of 2.7l with missing water sensor connected to an allarm pilot light
(17) and also to a buzzer. The sound of the buzzer caused by the lack of water at starting the machine is different from the
sound made to indicate the lack of water during normal funtioning. If there’s water in the tank and the buzzer goes on
anyway, please check the position of the water tank inside of the machine. The restoration of the suitable water level will
shut off the allarm pilot light (17) and the buzzer. If the water finishes during the normal funtioning the missing water
sensor will allow 15sec. of time to finish the coffee; once the coffee is done the water tank must be filled with water till the
max level indicated on the appliance body.
We suggest reading the instruction booklet carefully and checking the water level in the water tank regularly.
Water softener included (inserted on the plastic tube, inside the water tank): one way water softener for espresso
machines. It protects the machine from limestone residues. It needs to be replaced according to the water hardness and
consumption following the below table:
Water hardness
Quantity
10°F 90 lt
20°F 45 lt
27°F 35 lt
35°F 23 lt
45°F 20 lt
NB: It’s is necessary to replace the resin filter as indicated above otherwise the limestone residues can damage the coffee
machine (the warranty does not cover this type of damage).
Technical data:
Power supply: 220-230V: 50Hz - 220-230V: 60Hz
Coffee heating element: 1000W +1000W
Steam heating element: 1200W
Coffee pump pressure: 12/15 bar
Pump on coffee boiler (ULKA): 48W -- Pump on steam boiler (ULKA): 21W
Water tank capacity: 2,7 litri
Coffee boiler capacity: 250 ml – Steam boiler capacity: 400 ml
Dimensions (HxLxP): 43x30x42 cm – Net Weight: 17,7 kg
To be operated with ground coffee or coffee pods
