ESiEN09-06 Specifications
Specifications 9
Operation
range
Cooling Min °CDB -5
Max °CDB 43
Heating Min °CWB -20
Max °CWB 15
Sound level
(nominal)
Sound power dBA 72 78
Sound pressure dBA 54 57 58
Refrigerant Type R-410A
Charge kg 6,2 7,7 8,4
Control Electronic expansion valve
Nr of circuits 1
Refrigerant oil Type Synthetic (ether) oil
Charged volume l 1,7 2,1 4,3
Piping
connections
Liquid Type Brazing connection
Diameter
(OD)
mm 9,52
Gas Type Brazing connection
Diameter
(OD)
mm 15,9 19,1 22,2
Discharge gas Type
Diameter
(OD)
mm
Drain Quantity
Diameter
(OD)
mm
Heat insulation Both liquid and gas
Max total length m 55
Defrost method Reversed cycle
Defrost control Sensor for outdoor heat exchanger temperature
Capacity control method Inverter controlled
Capacity control [%] ~ 100
Safety devices High pressure switch
Fan driver overload protector
Overcurrent relay
Inverter overload protector
PC board fuse
Standard
accessories
Item Installation manual
Quantity 1
Standard
accessories
Item Operation manual
Quantity 1
Standard
accessories
Item Connection pipes
Quantity 4
Notes Nominal cooling capacities are based on: indoor temperature: 27°CDB/19°CWB, outdoor temperature: 35°CDB,
equivalent refrigerant piping: 7,5m, level difference: 0m.
Nominal heating capacities are based on: indoor temperature: 20°CDB, outdoor temperature: 7°CDB/6°CWB,
equivalent refrigerant piping: 7,5m, level difference: 0m.
Sound power level is an absolute value that a sound generates.
Sound pressure level is a relative value, depending on the distance and acoustic environment. For more details,
please refer to sound level drawings.
Sound values are measured in a semi-anechoic room.
ELECTRICAL SPECIFICATIONS ERQ125A7W1B ERQ200A7W1B ERQ250A7W1B
Power supply Name W1
Phase 3N~
Frequency Hz 50
Voltage V 400
Current Nominal
running
current (RLA)
Cooling A 5,1 7,5 11,3
Heating
A
5,8 8,2 11,1
Starting current (MSC) A 74
Zmax
-0,27
Minimum Ssc value kVA - 889 842
Min circuit amps (MCA) A 11,9 18,5 21,6
Max fuse amps (MFA) A 16 25
Total overcurrent amps
(TOCA)
A
15,6 16,5 31,5
Full load amps (FLA) A 0,4 0,7 0,9
Voltage range V 400 ±10%
Wiring
connections
For power
supply
Quantity 5
Remark Earth wire included
For
connection
with indoor
Quantity 2
Remark
F1 - F2
Power supply intake Both AHU and outdoor unit
TECHNICAL SPECIFICATIONS ERQ125A7W1B ERQ200A7W1B ERQ250A7W1B
ESiEN09-06.pdf 17 2/16/2010 4:42:25 PM
