Daikin EKEXV100 [8/13] Capacity tables
![Daikin EKEXV100 [8/13] Capacity tables](/views2/1763807/page8/bg8.png)
• Accessory • EKEXV
4
• Ventilation • EKEXV
6
4 Capacity tables
4 - 2 Heating Capacity Tables
EKEXV
AA
AB
AC
10.0 16.0 18.0 20.0 21.0 22.0 24.0
[°CDB] [°CWB] kW kW kW kW kW kW kW
50 7.0 6.0 6.6 6.6 6.6 6.3 6.1 5.9 5.5
63 7.0 6.0 8.4 8.4 8.4
8.0
7.7 7.5 7.0
80 7.0 6.0 10.5 10.5 10.5
10.0
9.7 9.4 8.7
100 7.0 6.0 13.1 13.1 13.1
12.5
12.1 11.7 10.9
125 7.0 6.0 16.8 16.8 16.8
16.0
15.5 15.0 13.9
140 7.0 6.0 18.9 18.9 18.9
18.0
17.4 16.8 15.7
200 7.0 6.0 26.2 26.2 26.2
25.0
24.2 23.4 21.8
250 7.0 6.0 33.1 33.1 33.0
31.5
30.5 29.5 27.5
400 7.0 6.0 52.4 52.4 52.4
50.0
48.4 46.8 43.6
500 7.0 6.0 66.0 66.0 66.0
63.0
61.0 59.0 54.9
3D090230
NOTES - ANMERKUNGEN - ƴLjǍdžNJǟǔdžNJǓ - NOTAS - REMARQUES - NOTE - OPMERKINGEN - ȝȞȖȚȓȥȎțȖȭ - NOTLAR
1. AA: Unit size
AA: Gerätegröße
$$ȂȑȖİșȠȢȝȠȞȐįĮȢ
AA: Tamaño de la unidad
AA : Taille de l’unité
AA: Dimensione unità
AA: unit grootte
$$Ɍɢɩɨɪɚɡɦɟɪɛɥɨɤɚ
AA: Ünite boyutu
2. AB: Outdoor air temperature
AB: Außenlufttemperatur
$%ĬİȡȝȠțȡĮıȓĮIJȠȣĮȑȡĮıIJȠʌİȡȚȕȐȜȜȠȞ
AB: Temperatura del aire exterior
AB: Température de l’air extérieur
AB: Temperatura aria esterna
AB: temperatuur buitenlucht
$%Ɍɟɦɩɟɪɚɬɭɪɚɧɚɪɭɠɧɨɝɨɜɨɡɞɭɯɚ
$%'ÕúRUWDPVÕFDNOÕ÷Õ
3. AC: On-coil air temperature [°C DB]
AC: Lufttemperatur am Wärmetauscher [°C TK]
$&ĬİȡȝȠțȡĮıȓĮİȟȦIJİȡȚțȠȪĮȑȡĮıIJȠıIJȠȚȤİȓȠ>&'%@
AC: Temperatura del aire en el serpentín [°C BS]
AC: Température de l’air sur serpentin [°CBS]
AC: Temperatura aria batteria [°C BS]
AC: luchttemperatuur voor spoel [°C DB]
$&Ɍɟɦɩɟɪɚɬɭɪɚɜɨɡɞɭɯɚɜɬɟɩɥɨɨɛɦɟɧɧɢɤɟ>&ɫɬ@
$&(úDQM|UoÕNÕúÕKDYDVÕFDNOÕ÷Õ>&.7@
